Sony DCR-PC53E - Mounted Parts Location; Pages from 4-76 to 4-77 Are Not Shown

4-75E
DCR-PC53E/PC55/PC55E
4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BOARDS
4-5. MOUNTED PARTS LOCATION
PD-239
Mounted parts location of the VC-379 board is not
shown.
Pages from 4-76 to 4-77 are not shown.
PD-239 BOARD
C7501 C-3
C7502 C-3
C7503 A-4
C7504 A-4
C7505 A-4
C7506 A-4
C7507 B-3
C7508 A-3
C7509 A-4
C7510 A-4
C7511 B-4
C7512 B-4
C7513 B-4
C7514 A-3
C7515 A-4
C7516 A-4
C7518 A-3
C7519 A-3
C7520 B-3
C7521 B-3
C7522 B-3
C7523 B-3
C7524 C-3
C7525 C-3
C7526 B-4
C7527 B-4
C7528 A-2
C7529 B-4
C7530 A-3
C7531 B-3
C7532 C-4
C7536 B-4
C7537 B-4
CL7503 B-3
CL7504 B-3
CL7505 B-3
CN7502 B-1
CN7503 C-3
CN7504 C-2
CN7505 C-4
CN7506 A-4
D7501 A-3
D7502 C-3
D7503 C-3
D7504 B-3
D7505 A-2
D7506 C-2
FB7501 A-4
IC7501 B-3
L7501 A-4
L7502 B-4
L7503 A-4
L7504 B-4
LND751 C-1
LND752 B-2
LND753 B-2
Q7501 C-4
Q7502 C-3
Q7503 A-3
Q7508 B-4
Q7509 A-2
Q7510 A-2
Q7511 B-4
Q7512 B-4
Q7513 B-4
Q7514 B-4
Q7515 C-4
Q7516 B-4
R7501 C-1
R7503 B-1
R7505 C-1
R7506 A-3
R7507 C-4
R7508 B-4
R7509 B-3
R7510 B-4
R7511 B-4
R7512 B-4
R7513 B-4
R7519 A-3
R7520 B-3
R7522 A-3
R7523 A-3
R7524 A-3
R7525 A-3
R7528 C-3
R7529 B-4
R7530 A-2
R7531 A-2
R7532 A-2
R7533 B-3
R7534 B-3
R7535 C-4
R7536 C-4
R7537 C-4
R7538 B-4
R7539 C-4
R7540 B-4
R7541 B-4
R7545 C-3
R7546 C-1
R7547 A-2
R7548 C-4
R7549 B-4
R7550 C-4
R7551 B-3
R7552 B-3
R7553 B-3
R7554 B-2
R7555 B-2
