5-13E
DCR-PC53E/PC55/PC55E
Ref. No. Part No. Description Ref. No. Part No. Description
< DIODE >
D7502 8-719-071-34 DIODE RB521S-30-TE61
D7503 8-719-071-34 DIODE RB521S-30-TE61
D7505 6-500-776-01 DIODE MAZW068H0LS0
D7506 8-719-071-34 DIODE RB521S-30-TE61
< FERRITE BEAD >
FB7501 1-414-760-21 FERRITE, EMI (SMD) (1608)
< IC >
IC7501 6-707-407-01 IC LRS57413
< COIL >
L7501 1-400-137-11 INDUCTOR 10uH
L7502 1-400-137-11 INDUCTOR 10uH
L7503 1-400-137-11 INDUCTOR 10uH
L7504 1-400-137-11 INDUCTOR 10uH
< TRANSISTOR >
Q7501 8-729-427-42 TRANSISTOR XP4211
Q7502 8-729-427-12 TRANSISTOR XP4111
Q7508 6-550-119-01 TRANSISTOR DTC144EMT2L
Q7509 6-550-150-01 TRANSISTOR SSM3J09FU (TE85L)
Q7510 8-729-053-84 TRANSISTOR SSM3KO9FU (T5LSONY1)
Q7511 8-729-041-23 TRANSISTOR NDS356AP
Q7512 8-729-041-23 TRANSISTOR NDS356AP
Q7513 8-729-042-26 TRANSISTOR 2SB1462J-QR (K8).SO
Q7514 8-759-054-48 IC C010-PW2000SV-V110
Q7515 8-759-054-48 IC C010-PW2000SV-V110
Q7516 8-729-037-61 TRANSISTOR UN9113J-(TX).SO
< RESISTOR >
R7501 1-216-864-11 SHORT CHIP 0
R7507 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R7508 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R7509 1-218-977-11 RES-CHIP 100K 5% 1/16W
R7510 1-218-949-11 RES-CHIP 470 5% 1/16W
R7511 1-218-949-11 RES-CHIP 470 5% 1/16W
R7512 1-218-949-11 RES-CHIP 470 5% 1/16W
R7513 1-218-949-11 RES-CHIP 470 5% 1/16W
R7519 1-218-975-11 RES-CHIP 68K 5% 1/16W
R7520 1-218-965-11 RES-CHIP 10K 5% 1/16W
R7522 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R7523 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R7528 1-218-965-11 RES-CHIP 10K 5% 1/16W
R7529 1-218-977-11 RES-CHIP 100K 5% 1/16W
R7530 1-218-977-11 RES-CHIP 100K 5% 1/16W
R7531 1-218-977-11 RES-CHIP 100K 5% 1/16W
R7533 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R7534 1-218-953-11 RES-CHIP 1K 5% 1/16W
R7537 1-218-969-11 RES-CHIP 22K 5% 1/16W
R7538 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R7539 1-218-950-11 RES-CHIP 560 5% 1/16W
R7540 1-218-969-11 RES-CHIP 22K 5% 1/16W
R7541 1-208-643-11 METAL CHIP 22 0.5% 1/16W
R7545 1-218-990-11 SHORT CHIP 0
R7546 1-216-864-11 SHORT CHIP 0
R7547 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R7549 1-218-953-11 RES-CHIP 1K 5% 1/16W
R7550 1-218-990-11 SHORT CHIP 0
R7554 1-220-803-81 RES-CHIP 4.7 5% 1/16W
R7555 1-220-803-81 RES-CHIP 4.7 5% 1/16W
************************************************************
CR-049 BOARD, COMPLETE
**********************
************************************************************
FB-223 BOARD, COMPLETE
**********************
VC-379 BOARD, COMPLETE
**********************
VC-379FB-223CR-049PD-239
Electrical parts list of the CR-049, FB-223 and
VC-379 board are not shown.
Pages from 5-14 to 5-22 are not shown.
