Sony DCR-SR50E - Page 65

5-9
5. REPAIR PARTS LIST
DCR-SR50E/SR60/SR60E/SR70E/SR80/SR80E_L2
Ref. No. Part No. Description Ref. No. Part No. Description
* 351 1-870-463-11 FP-516 FLEXIBLE BOARD
* 352 2-697-544-01 RETAINER, TERMINAL BOARD
353 X-2148-989-1 PANEL ASSY, BT
BH8301 1-780-064-21 BATTERY TERMINAL BOARD
5-1-8. BT PANEL BLOCK
J8301 1-815-792-11 CONNECTOR, DC-IN (7.2V) (DC IN)
#12 3-080-204-21 SCREW, TAPPING, P2 (Black)
HARDWARE LIST
#12
#12
BH8301
J8301
351
352
353
