5-11
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
DCR-SR50E/SR60/SR60E/SR70E/SR80/SR80E_L2
A-1202-631-A CK-166 BOARD, COMPLETE
**********************
< BATTERY >
0 BT7301 1-756-128-11 BATTERY, LITHIUM (SECONDARY)
< CAPACITOR >
C7304 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN7301 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P
CN7302 1-779-331-51 CONNECTOR, FFC/FPC 14P
CN7303 1-691-388-51 CONNECTOR, FFC/FPC 24P
* CN7304 1-817-554-51 CONNECTOR, FFC/FPC 6P
* CN7305 1-819-781-51 CONNECTOR, FPC (ZIF) 45P
< RESISTOR >
R7302 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R7303 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R7304 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R7305 1-218-960-11 RES-CHIP 3.9K 5% 1/16W
< SWITCH >
S7301 1-771-138-82 SWITCH, KEY BOARD (WIDE SELECT)
S7302 1-771-138-82 SWITCH, KEY BOARD (BACK LIGHT)
S7303 1-771-138-82 SWITCH, KEY BOARD (DISP/BATT INFO)
S7304 1-786-148-11 SWITCH, PUSH (1 KEY) (PANEL OPEN/CLOSE)
S7305 1-771-138-82 SWITCH, KEY BOARD (EASY)
S7306 1-771-138-82 SWITCH, KEY BOARD (RESET)
A-1168-382-A FP-372 FLEXIBLE BOARD, COMPLETE
******************************
< SWITCH >
S301 1-786-680-21 SWITCH, DETECTION (SMD) (PANEL REVERSE)
A-1202-635-A FP-514 FLEXIBLE BOARD, COMPLETE
******************************
< CAPACITOR >
C8101 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
CN8101 1-779-327-51 CONNECTOR, FFC/FPC 6P
* CN8102 1-817-555-51 CONNECTOR, FFC/FPC 8P
< DIODE >
D8101 6-500-512-01 DIODE CL-330IRS-X-TU (NIGHTSHOT)
D8102 8-719-064-07 DIODE SML-310LTT86
(CAMERA RECORDING)
< IC >
IC8101 6-600-163-01 IC RS-770
CK-166 FP-372 FP-514 FP-515 FP-516 FP-518
• Refer to page 5-1 for mark 0.
注意
電池の交換は，正しく行わないと破裂する恐れがあり
ます。電池を交換する場合には必ず同じ型名の電池
又は同等品と交換してください。
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
< RESISTOR >
R8101 1-216-805-11 METAL CHIP 47 5% 1/10W
A-1202-561-A FP-515 FLEXIBLE BOARD, COMPLETE
******************************
< RESISTOR >
R8401 1-218-929-11 RES-CHIP 10 5% 1/16W
R8402 1-218-929-11 RES-CHIP 10 5% 1/16W
R8403 1-218-929-11 RES-CHIP 10 5% 1/16W
R8404 1-218-929-11 RES-CHIP 10 5% 1/16W
R8405 1-218-929-11 RES-CHIP 10 5% 1/16W
R8406 1-218-929-11 RES-CHIP 10 5% 1/16W
R8407 1-218-929-11 RES-CHIP 10 5% 1/16W
R8408 1-218-929-11 RES-CHIP 10 5% 1/16W
R8409 1-218-929-11 RES-CHIP 10 5% 1/16W
R8410 1-218-929-11 RES-CHIP 10 5% 1/16W
R8411 1-218-929-11 RES-CHIP 10 5% 1/16W
R8412 1-218-929-11 RES-CHIP 10 5% 1/16W
R8413 1-218-929-11 RES-CHIP 10 5% 1/16W
R8414 1-218-929-11 RES-CHIP 10 5% 1/16W
R8415 1-218-929-11 RES-CHIP 10 5% 1/16W
R8416 1-218-929-11 RES-CHIP 10 5% 1/16W
* 1-870-463-11 FP-516 FLEXIBLE BOARD
*********************
(BH8301 and J8301 are not included in FP-516 flexible board.)
< BATTERY TERMINAL >
BH8301 1-780-064-21 BATTERY TERMINAL BOARD
< JACK >
J8301 1-815-792-11 CONNECTOR, DC-IN (7.2V) (DC IN)
A-1202-560-A FP-518 FLEXIBLE BOARD, COMPLETE
******************************
(CN8201 is not supplied, but this is included in FP-518 flexible complete
board.)
< CONNECTOR >
CN8201 (Not supplied) CONNECTOR, MULTIPLE (SOCKET)
(INTERFACE CONNECTOR)
< RESISTOR >
R8201 1-216-864-11 SHORT CHIP 0
To Next Page
