Sony DCR-SR50E - Page 68

5-12
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-SR50E/SR60/SR60E/SR70E/SR80/SR80E_L2
JK-317 PD-297
A-1202-643-A JK-317 BOARD, COMPLETE
**********************
< CONNECTOR >
CN8001 1-779-331-51 CONNECTOR, FFC/FPC 14P
CN8002 1-815-794-13 CONNECTOR (MULTIPLE) (A/V)
< FERRITE BEAD >
FB8001 1-500-444-11 FERRITE, EMI (SMD) (1608)
FB8002 1-500-444-11 FERRITE, EMI (SMD) (1608)
FB8003 1-500-444-11 FERRITE, EMI (SMD) (1608)
FB8004 1-500-444-11 FERRITE, EMI (SMD) (1608)
FB8005 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
FB8006 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
FB8007 1-500-444-11 FERRITE, EMI (SMD) (1608)
FB8008 1-500-444-11 FERRITE, EMI (SMD) (1608)
< JACK >
J8001 1-793-995-21 JACK, SUPER SMALL TYPE (REMOTE)
< VARISTOR >
VD8001 1-803-974-21 VARISTOR, CHIP (1608)
VD8002 1-803-974-21 VARISTOR, CHIP (1608)
VD8003 1-803-974-21 VARISTOR, CHIP (1608)
VD8004 1-801-923-11 VARISTOR, CHIP (1608)
VD8005 1-801-923-11 VARISTOR, CHIP (1608)
VD8006 1-801-923-11 VARISTOR, CHIP (1608)
A-1202-679-A PD-297 BOARD, COMPLETE
**********************
< CAPACITOR >
C6502 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C6503 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C6504 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6505 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C6506 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C6507 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C6508 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C6510 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C6511 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C6512 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C6516 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C6517 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C6518 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6519 1-125-889-91 CERAMIC CHIP 2.2uF 10% 10V
C6521 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6524 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6525 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C6526 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN6502 1-816-180-71 CONNECTOR, FPC (ZIF) 6P
* CN6503 1-794-322-51 CONNECTOR, FFC/FPC (ZIF) 6P
* CN6504 1-785-905-51 CONNECTOR, FFC/FPC (ZIF) 24P
* CN6505 1-785-905-51 CONNECTOR, FFC/FPC (ZIF) 24P
< DIODE >
D6503 8-719-074-67 DIODE EDZ-TE61-5.6B
* D6505 6-501-476-01 DIODE NSSW008CT-T071 (LCD BACKLIGHT)
* D6506 6-501-476-01 DIODE NSSW008CT-T071 (LCD BACKLIGHT)
* D6507 6-501-476-01 DIODE NSSW008CT-T071 (LCD BACKLIGHT)
< FERRITE BEAD >
FB6501 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
< IC >
* IC6501 8-753-242-24 IC CXM3018R-T4
< COIL >
L6501 1-400-588-11 INDUCTOR 10uH
L6502 1-400-588-11 INDUCTOR 10uH
L6504 1-400-588-11 INDUCTOR 10uH
< TRANSISTOR >
Q6501 8-729-427-37 TRANSISTOR XP411F-TXE
Q6502 8-729-427-67 TRANSISTOR XP421F-TXE
Q6503 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q6504 6-550-234-01 TRANSISTOR UNR32A300LS0
Q6505 8-729-041-23 TRANSISTOR NDS356AP
< RESISTOR >
R6502 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R6503 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R6504 1-218-975-11 RES-CHIP 68K 5% 1/16W
R6508 1-218-949-11 RES-CHIP 470 5% 1/16W
R6509 1-218-953-11 RES-CHIP 1K 5% 1/16W
R6510 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R6515 1-218-965-11 RES-CHIP 10K 5% 1/16W
R6516 1-218-978-11 RES-CHIP 120K 5% 1/16W
R6517 1-218-977-11 RES-CHIP 100K 5% 1/16W
R6518 1-218-989-11 RES-CHIP 1M 5% 1/16W
Electrical parts list of the VC-463 board is
not shown.
Pages 5-13 to 5-20 are not shown.
