Sony DSC-H2 - Page 48

5-10
DSC-H2_L2
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
A-1176-913-A AF-105 FLEXIBLE BOARD, COMPLETE
******************************
(D001 (AF LED) is not supplied, but this is included
in AF-105 flexible board complete.)
< DIODE >
D001 Not supplied DIODE DOR5073 (AF LED)
(D001 (AF LED) is not supplied, but this is included
in AF-105 flexible board complete.)
< SWITCH >
S001 1-762-805-21 SWITCH, PUSH (1 KEY) (LENS COVER OPEN)
************************************************************
A-1176-911-A CD-619 BOARD, COMPLETE
**********************
(IC002 is not included in this COMPLETE board.)
< CAPACITOR >
C002 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C004 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C005 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C006 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C007 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
* CN001 1-816-057-51 CONNECTOR, FPC (ZIF) 39P
< FERRITE BEAD >
FB001 1-400-620-21 INDUCTOR, FERRITE BEAD (1005)
< IC >
IC001 8-753-230-85 IC CXA3691EN-T9
IC002 A-1176-034-A CCD BLOCK ASSY (CCD IMAGER)
(IC002 is not included in this COMPLETE of CD-619 board.)
< TRANSISTOR >
Q001 6-550-119-01 TRANSISTOR DTC144EMT2L
< RESISTOR >
R002 1-218-990-81 SHORT CHIP 0
R003 1-218-982-11 RES-CHIP 270K 5% 1/16W
R004 1-218-989-11 RES-CHIP 1M 5% 1/16W
R007 1-218-981-11 RES-CHIP 220K 5% 1/16W
R009 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
************************************************************
A-1176-915-A JK-306 FLEXIBLE BOARD, COMPLETE
******************************
< CONNECTOR >
CN001 1-794-962-11 CONNECTOR, SQUARE TYPE (USB 5P)
< JACK >
J001 1-793-620-41 JACK (A/V OUT)
************************************************************
A-1176-912-A MS-307 BOARD, COMPLETE
***********************
< CAPACITOR >
C301 1-100-786-91 TANTAL. CHIP 22uF 20% 6.3V
C302 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
* CN301 1-816-644-51 FFC/FPC CONNECTOR (LIF) 12P
CN302 1-817-827-11 MEMORY STICK DUO CONNECTOR
< FERRITE BEAD >
FB301 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB302 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB303 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB304 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
< RESISTOR >
R302 1-218-953-11 RES-CHIP 1K 5% 1/16W
R303 1-218-940-11 RES-CHIP 82 5% 1/16W
R304 1-218-940-11 RES-CHIP 82 5% 1/16W
R305 1-218-990-81 SHORT CHIP 0
R306 1-218-990-81 SHORT CHIP 0
************************************************************
A-1176-908-A PL-045 BOARD, COMPLETE
**********************
(RY201 is not included in this COMPLETE of PL-045 board.)
< CAPACITOR >
C201 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
* CN201 1-816-654-51 FFC/FPC CONNECTOR (LIF) 6P
< DIODE >
D202 8-719-988-61 DIODE 1SS355TE-17
D203 6-500-776-01 DIODE MAZW068H0LS0
< RELAY >
RY201 1-455-038-11 SOLENOID, PLANGER
< SWITCH >
S201 1-786-179-31 SWITCH, PUSH (1KEY)(FLASH POP UP)
************************************************************
A-1176-909-A ST-142 BOARD, COMPLETE
**********************
(C105 is not included in this COMPLETE of ST-142 board.)
< CAPACITOR >
C101 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C102 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C103 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
0 C105 1-112-763-11 ELECT 320uF 330V
C106 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
• Refer to page 5-1 for mark 0.
AF-105 CD-619 JK-306 MS-307 PL-045
Be sure to read “Precautions upon replacing CCD imager”
on page 4-3 when changing the CCD imager.
ST-142
Ver. 1.1 2006. 06
