Sony DSC-H2 - Page 49

5-11E
DSC-H2_L2
Ref. No. Part No. Description Ref. No. Part No. Description
< CONNECTOR >
* CN101 1-816-644-51 FFC/FPC CONNECTOR (LIF) 12P
< DIODE >
D101 8-719-056-54 DIODE MAZS068008SO
0 D102 6-501-096-01 DIODE CRF02 (TE85R)
< IC >
IC101 6-707-555-01 IC TPS65552RGTR
< COIL >
L101 1-456-995-22 INDUCTOR 4.7uH
< TRANSISTOR >
Q101 6-550-891-01 TRANSISTOR GT8G133 (T2LSONY.Q)
< RESISTOR >
R103 1-243-975-11 METAL CHIP 4.7M 5% 1/16W
R104 1-218-935-11 RES-CHIP 33 5% 1/16W
< TRANSFORMER >
0 T101 1-443-850-21 DC-DC CONVERTER TRANSFORMER
************************************************************
A-1176-914-A ST-144 BOARD, COMPLETE
**********************
< CAPACITOR >
C002 1-100-758-11 CERAMIC CHIP 0.047uF 10% 250V
C003 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
< DIODE >
D001 6-500-811-01 DIODE RR255L-400TE25
< COIL >
L001 1-456-193-11 COIL, TRIGGER
< RESISTOR >
R001 1-216-121-11 RES-CHIP 1M 5% 1/10W
R002 1-216-097-11 RES-CHIP 100K 5% 1/10W
************************************************************
A-1176-910-A SW-473 BOARD, COMPLETE
***********************
< CAPACITOR >
C402 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C405 1-100-743-91 CERAMIC CHIP 2.2uF 20% 16V
C406 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C408 1-100-966-91 CERAMIC CHIP 10uF 20% 10V
C409 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
< CONNECTOR >
* CN401 1-815-333-51 CONNECTOR, FPC (ZIF) 33P
* CN402 1-816-654-51 FFC/FPC CONNECTOR (LIF) 6P
* CN403 1-815-333-51 CONNECTOR, FPC (ZIF) 33P
< DIODE >
D501 8-719-056-23 DIODE MA2S111-(K8).SO
D502 6-500-776-01 DIODE MAZW068H0LS0
D503 8-719-064-07 DIODE SML-310LTT86 (ACCESS)
< COIL >
L402 1-400-588-11 INDUCTOR 10uH
L403 1-400-588-11 INDUCTOR 10uH
< RESISTOR >
R405 1-218-973-11 RES-CHIP 47K 5% 1/16W
R501 1-218-962-11 RES-CHIP 5.6K 5% 1/16W
R502 1-218-970-11 RES-CHIP 27K 5% 1/16W
R503 1-218-962-11 RES-CHIP 5.6K 5% 1/16W
R504 1-218-970-11 RES-CHIP 27K 5% 1/16W
R505 1-208-671-11 METAL CHIP 330 0.5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB501 1-234-376-11 RES, NETWORK 2.2K (1005X4)
RB502 1-234-376-11 RES, NETWORK 2.2K (1005X4)
< SWITCH >
S501 1-786-157-11 SWITCH, TACTILE (MENU)
S502 1-786-157-11 SWITCH, TACTILE (DISP)
S503 1-786-157-11 SWITCH, TACTILE (LEFT)
S504 1-786-525-31 TACTILE SWITCH (ZOOM W)
S505 1-786-157-11 SWITCH, TACTILE (UP)
S506 1-786-157-11 SWITCH, TACTILE (SET)
S507 1-786-157-11 SWITCH, TACTILE (DOWN)
S508 1-786-525-31 TACTILE SWITCH (ZOOM T)
S509 1-786-157-31 SWITCH, TACTILE (DUST)
S510 1-786-157-11 SWITCH, TACTILE (RIGHT)
************************************************************
SY-150 BOARD, COMPLETE
**********************
Electrical parts list of the SY-150 board is not
shown.
Pages from 5-12 to 5-15 are not shown.
ST-142 ST-144 SW-473 SY-150
• Refer to page 5-1 for mark 0.
