Sony DSC-P10 - Electrical Parts List

— 5 —
DSC-P10/P12
A-7078-690-A SY-83 BOARD, COMPLETE (SERVICE)
******************************
< CAPACITOR >
C042 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C104 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C106 1-127-569-91 TANTAL. CHIP 100uF 20% 4V
< CONNECTOR >
CN801 1-794-411-21 CONNECTOR, FFC/FPC (LIF) 8P
< DIODE >
D006 6-500-186-01 DIODE MA2SD24008S0
D007 6-500-186-01 DIODE MA2SD24008S0
D008 6-500-186-01 DIODE MA2SD24008S0
D009 6-500-186-01 DIODE MA2SD24008S0
D011 6-500-186-01 DIODE MA2SD24008S0
D801 6-500-186-01 DIODE MA2SD24008S0
< IC >
IC301 6-701-957-01 IC M50230FP-DF0T
IC402 6-803-134-01 IC MB89097LGA-G-157-ER
< COIL >
L003 1-419-627-21 INDUCTOR 10uH
L005 1-419-627-21 INDUCTOR 10uH
< TRANSISTOR >
Q008 6-550-408-01 TRANSISTOR QS5U26TR
A-7078-690-B SY-83 BOARD, COMPLETE (SERVICE)
******************************
< CAPACITOR >
C042 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C104 1-100-786-91 TANTAL. CHIP 22uF 20% 6.3V
C106 1-128-964-91 TANTAL. CHIP 100uF 20% 6.3V
< CONNECTOR >
CN801 1-817-549-11 CONNECTOR, FFC/FPC (LIF) 8P
< DIODE >
D006 8-719-056-23 DIODE MA2S111-(K8). SO
D007 6-500-619-01 DIODE RB520S-40TE61
D008 6-500-619-01 DIODE RB520S-40TE61
D009 6-500-619-01 DIODE RB520S-40TE61
D011 6-500-619-01 DIODE RB520S-40TE61
D801 6-500-619-01 DIODE RB520S-40TE61
< IC >
IC301 6-702-931-01 IC M50230FP-DF1T
IC402 6-803-602-01 IC MB89097LGA-G-163-ER
< COIL >
L003 1-419-627-11 INDUCTOR 10uH
L005 1-419-627-11 INDUCTOR 10uH
< TRANSISTOR >
Q008 6-550-405-01 TRANSISTOR CPH5815-TL-E
-: Points changed portion.
5-2. ELECTRICAL PARTS LIST
• Change of repair parts (SY-83 Board)
Page Before change After change
Ref. No. Part No. DescriptionRef. No. Part No. Description
5-9
]
[
[
[
]
=
=
=
=
=
=
=
=
]
]
=
5-10
5-11
