5-8
Ref. No. Part No. Description Ref. No. Part No. Description
DSC-W150/W170_L2
< SWITCH >
S101 1-786-819-22 TACTILE SWITCH (SHUTTER)
S102 1-771-844-21 SWITCH, TACTILE (SMD) (POWER)
< TRANSFORMER >
0 T001 1-445-108-21 TRANSFORMER, D.C-D.C CONVERTER
A-1528-434-A SW-529 BOARD, COMPLETE
***********************
(S010 (Mode dial) is not supplied, but this is included in SW-529 complete
board.)
< CONNECTOR >
* CN001 1-820-634-51 CONNECTOR, FPC (LIF (NON-ZIF))
< COMPOSITION CIRCUIT BLOCK >
RB001 1-234-376-11 RES, NETWORK 2.2K (1005X4)
RB002 1-234-376-11 RES, NETWORK 2.2K (1005X4)
RB003 1-234-376-11 RES, NETWORK 2.2K (1005X4)
RB004 1-234-376-11 RES, NETWORK 2.2K (1005X4)
< SWITCH >
* S001 1-786-914-31 SWITCH, TACTILE (MENU)
* S002 1-786-914-31 SWITCH, TACTILE (HOME)
* S003 1-786-914-31 SWITCH, TACTILE (W (ZOOM))
* S004 1-786-914-31 SWITCH, TACTILE (b (MACRO))
* S005 1-786-914-31 SWITCH, TACTILE (V (SELF-TIMER))
* S006 1-786-914-31 SWITCH, TACTILE (v (DISP))
* S007 1-786-914-31 SWITCH, TACTILE (z)
* S008 1-786-914-31 SWITCH, TACTILE (T (ZOOM))
* S009 1-786-914-31 SWITCH, TACTILE (B (FLASH))
S010 (Not supplied) SWITCH, ROTARY (MODE DIAL)
(S010 (Mode dial) is supplied including in SW-529 complete board.)
* S011 1-786-914-31 SWITCH, TACTILE (SLIDESHOW)
* S012 1-786-914-31 SWITCH, TACTILE (N)
ST-180 SW-529
Electrical parts list of the SY-194 board is
not shown.
Page 5-9 to 5-12 are not shown.
• Refer to page 5-1 for mark 0.
