DSX-B700/B700W/B710D
45
Sony CONFIDENTIAL
For Authorized Servicer
Pin No. Pin Name I/O Description
63 KEY_ACK1
I Key acknowledge signal (wake up signal) input from the front panel key
64 SIRCS I Remote control signal input from the remote control receiver
65 NC O Not used
66, 67 DEBUG_6, DEBUG_7 O Debug test terminal Not used
68 BEEP O Beep sound output to the power amplifi er
69 REMOTE_10K O Pull-up resistor (10K) selection signal output terminal (for rotary commander) Not used
70 REMOTE_1K O Pull-up resistor (1K) selection signal output terminal (for steering control)
71 RE_ON O Jog dial pulse pull-up signal output terminal
72, 73 RE_IN1, RE_IN0 I Jog dial pulse signal input from the rotary encoder
74 DAB_SCK O IIC clock signal output to the DAB audio DSP (DSX-B710D only)
75 DAB_SDA I/O Two-way IIC data bus with the DAB audio DSP (DSX-B710D only)
76 DAB_PWR O
DAB power on/off control signal output to the DAB audio DSP “H”: power on
(DSX-B710D only)
77 NC - Not used
78, 79 KEY_1, KEY_0 I Front panel key input terminal
80 RC_IN0 I Steering control key input terminal
81 RC_IN1 I Steering control shift key input terminal
82 MECHA_ON I Power detection signal input terminal for CD mechanism section Not used
83 INDICATE_+B I Battery voltage level check signal input terminal
84 EN_USB O USB power on/off control signal output to the VBUS switch “H”: power on
85 VSS4 - Ground terminal
86 VDD4 - Power supply terminal (+3.3V)
87 to 89 NC O Not used
90 PANEL_DET
I Front panel detach/attach detection signal input terminal Fixed at “L” in this unit
91 to 93 NC O Not used
94 LOE/LIM_SW I Limit in detection switch input terminal Not used
95 FILT I Filter terminal for PLL
96 LO_EJ O Loading/eject motor drive signal output terminal Not used
97 12EJE_SW I Disc insert detection switch input terminal Not used
98 LOS_SW I Self loading position detection switch input terminal Not used
99 DRV_MUTE O Driver control muting signal output terminal Not used
100 DRV_CONT O Driver control signal output terminal Not used
