External view
3450
33 18
1-8. Signal Inputs and Outputs
REMOTE 2 PARALLEL I/O: 50-pin (female)
Pin No. I/O
**
**
*1
Setting change
**
**
*2
Signal Description
1INO FF CLOSURE SW (FF)
2 OUT X REC SW PANEL REC SW OUT
3 OUT X PLAY SW PANEL PLAY SW OUT
4 OUT X STOP SW PANEL STOP SW OUT
5 OUT X ENTRY SW PANEL ENTRY SW OUT
6 OUT X REF SYSTEM ALARM Non-REFERENCE
7 OUT X CF LOCK COLOR FRAME LOCK STATUS
8 OUT X DRUM LOCK LOCK STATUS OF DRUM SERVO
9 OUT X CAP LOCK LOCK STATUS OF CAPSTAN SERVO
10 OUT O CUE PRESET EDIT PRESET STATUS of the CUE Channel
11 OUT O TC PRESET EDIT PRESET STATUS of the TC Channel
12 OUT O OXIDE/METAL OXIDE/METAL TAPE STATUS
13 OUT O TAPE THICKNESS TAPE THICKNESS STATUS
14 OUT X SPARE SPARE
15 OUT X SPARE SPARE
16 —— —— +12V (Maximum output current 50 mA)
17 —— —— GND SIGNAL GND
18 IN O PREROLL CLOSURE SW (PREROLL)
19 IN O STBY ON CLOSURE SW (STANDBY ON)
20 IN O REW CLOSURE SW (REW)
21 IN O ENTRY CLOSURE SW (ENTRY IN)
22 IN O STBY OFF CLOSURE SW (STANDBY OFF)
23 IN O EJECT CLOSURE SW (EJECT)
24 OUT X REC REC STATUS
25 OUT X CH CONDITION RED CHANNEL CONDITION RED STATUS
26 OUT O ASSEMBLE PRESET ASSEMBLE PRESET STATUS
27 OUT O EDIT OUT EDIT STATUS
28 OUT O EJECT OUT EJECT STATUS
29 OUT O ANALOG/DIGITAL ANALOG/DIGITAL STATUS
30 OUT O REEL HUB REEL HUB STATUS
31 OUT X REM2 SETTING DATA RESET REMOTE2 SETTING DATA RESET STATUS
32 OUT X ALL REC INHIBIT ALL REC INHIBIT STATUS
33 —— —— GND
34 IN O PLAY CLOSURE SW (PLAY)
35 IN O STOP CLOSURE SW (STOP)
(Continue)
