CAMERA ADAPTOR
SPECIFICATIONS
Inputs/Outputs VTR/CCU/CMA connector: Sony Q-type,
14-pin
DC IN: XLR-type, 4-pin
MIC IN: XLR-type, 3-pin
GEN LOCK IN: BNC-type
EAR: mini jack
INTERCOM: mini intercom jack
S VIDEO OUT: mini DIN-type, 4-pin
AUDIO OUT: phono jack
Power requirements
12V DC
Power consumption
0.8 W
Operating temperature
-5°C to +45°C (23°F to 113°F)
Storage temperature
20°C to +60°C (—4°F to +140°F)
Weight 1.2 kg (2 Ib 10 oz)
Dimensions 118 x 205 x 187 mm
(49/4 x 8/3 x 79/s inches)
Supplied accessories
Screws for attaching the CA-327/327P.
M4 x 6 (2)
M4 x 12 (2)
Operating instructions (1)
Design and specifications are subject to change without
SONY.
SERVICE MANUAL
