Help Guide
Shotgun Microphone
ECM-B10
Attaching/removing to/from the camera
Attach the shotgun microphone to a camera.
Note
Before attaching/removing this unit to/from a camera, turn off the power to the camera.
Remove the connector protect cap from this unit.
1
Attach this unit to the camera (
) and rotate the lock dial in the “LOCK” direction ( ) to firmly secure the
unit.
Attaching this unit to a camera automatically switches the audio input from the built-in microphone to the external
microphone (this unit). When it is difficult to insert the Multi Interface foot into the shoe, rotate the lock dial
counterclockwise until it stops, and then try again.
2
Operate the camera to start recording.
For details, refer to the Help Guide provided for the camera.
3
To Next Page
