Sony ECM-S1 - Page 35

Others
Design and specifications are subject to change without notice.
5-054-814-11(1) Copyright 2023 Sony Corporation
Sampling frequency/the number of
quantization bits
48 kHz/16 bit, 48 kHz/24 bit
*1
Frequency response 20 Hz - 20 000 Hz
Pickup pattern (selectable)
Monaural, Uni-directional/Monaural, Omni-directional/Stereo, Uni-
directional
Front sensitivity
*2
–20 dBFS (0.1 Pa, 1 kHz)
Intrinsic noise
*2 *3 *4
19 dB SPL or less (0 dB = 2×10
-5
Pa)
Wind noise
*2 *4 *5
30 dB SPL or less
Maximum input sound pressure level
120 dB SPL
*2 *6
Dynamic range
*3
101 dB or more
Headphone out jack Ø3.5 mm mini jack (stereo)
USB port USB Type-C port
Power requirements Built-in lithium-ion battery (approx. 3.85 V)
Rated Voltage 5 V
Power consumption (Approx.) 0.16 W
Continuous operating time (Approx.) 13 hours (with the fully charged built-in battery)
Charging time (Approx.)
2 hours
*7
(via a computer)
Dimensions (Approx.)
63 mm × 137.5 mm × 63 mm (2 1/2 in. × 5 1/2 in. × 2 1/2 in.) (W/H/D)
(including the stand)
Mass (Approx.) 157 g (5.6 oz.) (including the stand)
Videos recorded with 24-bit audio may not be played back normally on devices or software incompatible with 24-bit audio, resulting in
unexpectedly loud volumes or no sound.
*1
Acquired while “8” is selected by the AUDIO LEVEL dial.
*2
Acquired while “DIGITAL” is selected by the slide switch.
*3
Acquired while
(Monaural, Uni-directional) is selected by the directivity selection switch and “LC” is selected by the filter switch.
*4
Equivalent sound pressure level value converted from the average value of the noise that is output from the microphone when an air stream with
a wind velocity of 2 m/sec. is applied to the microphone from every direction. (0 dB = 2×10
-5
Pa)
*5
Equivalent sound pressure level value converted from the input level value that is acquired when 1% waveform distortion is produced by 1 kHz
output signals from the microphone. (0 dB = 2×10
-5
Pa)
*6
Time period required for charging the empty rechargeable batteries via the USB charging port (CDP - Charging Downstream Port) on the
computer to full capacity. It may vary depending on the using condition.
*7
Operating temperature 0 °C to 40 °C (32 °F to 104 °F)
Storage temperature –20 °C to +55 °C (–4 °F to 131 °F)
35
