Help Guide
Wireless/Streaming Microphone
ECM-S1
Monitoring the audio
When recording with the microphone and the connected computer or smartphone via the USB connection, you can
connect headphones (commercially available) to the microphone for audio monitoring.
Note
While the microphone and the computer or smartphone are not connected via the USB connection, audio monitoring with the
connected headphones is not possible.
Related Topic
Recording with the microphone and the computer or smartphone connected via the wired connection
Adjusting the headphone volume level
Adjusting the audio mixing ratio
Lamp indications
5-054-814-11(1) Copyright 2023 Sony Corporation
Connect the microphone to a computer or a smartphone that is up and running with a USB Type-C cable
(commercially available).
1
Connect headphones (commercially available) to the headphone out jack on the microphone.
2
Launch the software capable of audio recording on the computer or smartphone, and then select [ECM-S1].
3
24
