Command List
Lens Control System Inquiry Commands ............ Command Packet 8x 09 7E 7E 01 FF
Byte Bit Comments
0
7
6
5
4
Destination Address
3
2
1
0
Source Address
1
7 0 Completion Message (50h)
6 1
5 0
4 1
3 0
2 0
1 0
0 0
2
7 0
6 0
5 0
4 0
3
2
1
0
R Gain (H)
3
7 0
6 0
5 0
4 0
3
2
1
0
R Gain (L)
4
7 0
6 0
5 0
4 0
3
2
1
0
B Gain (H)
5
7 0
6 0
5 0
4 0
3
2
1
0
B Gain (L)
Byte Bit Comments
6
7 0
6 0
5 0
4 0
3
2
1
0
WB Mode
7
7 0
6 0
5 0
4 0
3
2
1
0
Aperture Gain
8
7 0
6 0
5 0
4
3
2
1
0
Exposure Mode
9
7 0
6 0
5 High-Resolution 1: On 0: Off
4
Wide-D (1: Other than Off,
0: Off)
3 0
2 Back Light 1:On 0:Off
1 Exposure Comp. 1:On 0:Off
0 Slow Shutter 1:Auto 0:Manual
10
7 0
6 0
5 0
4
3
2
1
0
Shutter Position
11
7 0
6 0
5 0
4
3
2
1
0
Iris Position
Byte Bit Comments
12
7 0
6 0
5 0
4 0
3
2
1
0
Gain Position
13
7 0
6 0
5 0
4
3
2
1
0
Bright Position
14
7 0
6 0
5 0
4 0
3
2
1
0
Exposure Comp. Position
15
7 1 Terminator (FFh)
6 1
5 1
4 1
3 1
2 1
1 1
0 1
