Command List
Byte Bit Comments
0
7
6
5
4
Destination Address
3
2
1
0
Source Address
1
7 0 Completion Message (50h)
6 1
5 0
4 1
3 0
2 0
1 0
0 0
2
7 0
6 0
5 0
4 0
3 0
2 Auto ICR 1: On 0: Off
1 0
0 Power 1: On 0: Off
3
7 0
6 Stabilizer (1: On, 0: Off)
5 0
4 ICR 1: On 0: Off
3 0
2 0
1 0
0 0
4
7 0
6 0
5 0
4 Inconsistent
3 Inconsistent
2 Inconsistent
1 0
0 0
5
7 0
6 0
5 0
4 0
3
2
1
0
Picture Effect Mode
Byte Bit Comments
6
7 0
6 0
5 0
4 0
3 0
2 0
1 0
0 0
7
7 0
6 0
5 0
4 0
3 0
2 0
1 0
0 0
8
7 0
6 0
5 0
4 0
3
2
1
0
Camera ID (HH)
9
7 0
6 0
5 0
4 0
3
2
1
0
Camera ID (HL)
10
7 0
6 0
5 0
4 0
3
2
1
0
Camera ID (LH)
11
7 0
6 0
5 0
4 0
3
2
1
0
Camera ID (LL)
Byte Bit Comments
12
7 0
6 0
5 Inconsistent
4
Memory 1: Provided 0: Not
provided
3 Inconsistent
2
ICR 1: Provided 0: Not
provided
1
Stabilizer (1: Provided, 0: Not
provided)
0 System 1:PAL 0:NTSC
13
7 0
6 0
5 0
4 0
3
2
1
0
Inconsistent
14
7 0
6 0
5
4
3
2
1
0
Inconsistent
15
7 1 Terminator (FFh)
6 1
5 1
4 1
3 1
2 1
1 1
0 1
Other Inquiry Commands .............................................. Command Packet 8x 09 7E 7E 02 FF
