TA-F419R/F519R
INPUT
JOINT
(A) JOINT (C)
JOINT
(D)
KEY
Ref. No. Part No.
Description
Remark Ref.
No.
Part
No. Description
Remark
< RESISTOR >
* 1-644-630-11
JOINT (D) BOARD
***************
R115
1-247-713-11
CARBON IK
5%
1/4W
R116
1-247-713-11
CARBON IK
5%
1/4W
<
CONNECTOR >
R117
1-259-500-11
CARBON 1M
5%
1/6W
R118
1-259-500-11
CARBON 1M 5%
1/6W
*
CNJ800
1-691-175-11
CONNECTOR (BOARD TO BOARD)
5P
R119
1-259-500-11
CARBON 1M 5%
1/6W
R120
1-259-500-11
CARBON 1M
5%
1/6W
R121
1-259-500-11
CARBON 1M
5%
1/6W
R215
1-247-713-11
CARBON
IK 5%
1/4W
R216
1-247-713-11
CARBON
IK
5%
1/4W
R217
1-259-500-11
CARBON 1M
5%
1/6W
R218
1-259-500-11
CARBON 1M
5%
1/6W
R219
1-259-500-11
CARBON
1M
5%
1/6W
R220
1-259-500-11
CARBON 1M
5%
1/6W
R221
1-259-500-11
CARBON 1M
5%
1/6W
R350
1-247-700-11
CARBON
100 5%
1/4W
(F419R: G/F519R: G)
R450
1-247-700-11
CARBON 100
5%
1/4W
(F419R:
G/F519R:
G)
< VARIABLE RESISTOR
>
RV300
1-241-913-11
RES, VAR,
CARBON 120K/120K (VOLUME)
<
SWITCH
>
CNP801
1-691-162-11
PIN, CONNECTOR
5P
************************************************************
*
A-4347-648-A
KEY BOARD, COMPLETE
(F419R:
AEP/F519R: AEP)
*
A-4347-649-A KEY BOARD,
COMPLETE
(F419R:
G/F519R:
G)
*************************************
<
CAPACITOR >
C705
1-164-085-11
CERAMIC
0. OOluF
10% 50V
C706
1-126-176-11
ELECT
220uF
20%
10V
C707
1-136-161-00
FILM
0. 047uF
5% 50V
C724
1-124-927-11
ELECT 4.
7uF
20%
100V
C750
1-126-233-11
ELECT
22uF
20% 50V
C751
1-126-233-11
ELECT 22uF
20%
50V
C752
1-164-085-11
CERAMIC
0.
OOluF
10%
50V
5102
1-571-115-11
SWITCH,
SLIDE
(REC
OUT SELECTOR)
5103
1-692-142-11
SWITCH,
ROTARY (WITH MOTOR)
(INPUT SELECTOR)
************************************************************
< CONNECTOR
>
*
CNJ300
1-565-321-11
SOCKET, CONNECTOR
(PC BOARD) 8P
*
CNJ701
1-568-865-11
SOCKET, CONNECTOR
23P
CNJ900
1-562-088-00
SOCKET, CONNECTOR
9P
*
CNJ903
1-561-652-00
SOCKET,
CONNECTOR 12P
*
1-644-628-11
JOINT (A) BOARD
***************
<
DIODE
>
D703
8-719-987-63
DIODE
1N4148M
<
CONNECTOR > D704
8-719-987-63
DIODE
1N4148M
D708
8-719-987-63
DIODE 1N4148M
*
CNJ501
1-691-180-11
CONNECTOR (BOARD TO
BOARD)
10P D709
8-719-987-63
DIODE
1N4148M
D710
8-719-987-63
DIODE 1N4148M
CNP101
1-691-167-11
PIN, CONNECTOR 10P
D711
8-719-987-63
DIODE
1N4148M
************************************************************
D712
8-719-987-63
DIODE
1N4148M
D713
8-719-987-63
DIODE
1N4148M
»
1-644-620-11
JOINT
(C)
BOARD D714
8-719-987-63
DIODE 1N4148M
D715
8-719-987-63
DIODE
1N4148M
D716
8-719-987-63
DIODE 1N4148M
<
CONNECTOR >
D717
8-719-313-69
DIODE
SEL3210S-CD
*
CNP901
1-580-854-11
PIN, CONNECTOR (PC BOARD) 6P
D718
8-719-313-72
LED
SEL3810A-CD
*
CNP902
1-580-854-11
PIN, CONNECTOR (PC BOARD) 6P
D720
8-719-018-46
LED
SEL3510C-CD
*
CNP903
1-560-443-11
PIN, CONNECTOR 12P
D721
8-719-018-46
LED
SEL3510C-CD
D722
8-719-018-46
LED
SEL3510C-CD
************************************************************
D723
8-719-018-46
LED
SEL3510C-CD
D724
8-719-018-46
LED
SEL3510C-CD
D725
8-719-018-46
LED
SEL3510C-CD
^
