108
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
R6439 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R6440 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R6441 1-216-675-91 METAL CHIP 10K 0.5% 1/10W
R6442 1-216-039-00 RES-CHIP 390 5% 1/10W
R6455 1-216-295-91 SHORT 0
R6456 1-216-097-91 RES-CHIP 100K 5% 1/10W
R6457 1-216-075-00 RES-CHIP 12K 5% 1/10W
R6458 1-216-089-91 RES-CHIP 47K 5% 1/10W
R6459 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6460 1-249-393-11 CARBON 10 5% 1/4W
R6461 1-249-411-11 CARBON 330 5% 1/4W
R6462 1-249-406-11 CARBON 120 5% 1/4W
R6463 1-216-095-00 RES-CHIP 82K 5% 1/10W
R6464 1-216-079-00 RES-CHIP 18K 5% 1/10W
< CAPACITOR >
C4316 1-104-664-11 ELECT 47UF 20.00% 25V
C4317 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4318 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4319 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4320 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4321 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4322 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4324 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4325 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C4329 1-126-963-11 ELECT 4.7UF 20.00% 50V
C4330 1-137-581-11 FILM 0.1UF 5.00% 100V
C4331 1-126-959-11 ELECT 0.47UF 20.00% 50V
C4332 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4333 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4334 1-126-967-11 ELECT 47UF 20.00% 50V
C4336 1-126-967-11 ELECT 47UF 20.00% 50V
C4338 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4340 1-126-967-11 ELECT 47UF 20.00% 50V
C4342 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C4343 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4344 1-163-809-11 CERAMIC CHIP 0.047UF 10.00% 25V
C4345 1-126-967-11 ELECT 47UF 20.00% 50V
C4346 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4347 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4348 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4349 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4350 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4351 1-163-009-11 CERAMIC CHIP 0.001UF 10.00% 50V
C4352 1-126-967-11 ELECT 47UF 20.00% 50V
C4353 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C4354 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C4355 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4356 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4357 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4358 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4359 1-164-161-11 CERAMIC CHIP 0.0022UF 10.00% 50V
C4360 1-126-963-11 ELECT 4.7UF 20.00% 50V
C4362 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4363 1-126-967-11 ELECT 47UF 20.00% 50V
C4364 1-126-967-11 ELECT 47UF 20.00% 50V
C4366 1-163-059-91 CERAMIC CHIP 0.01UF 10.00% 50V
C4367 1-104-760-11 CERAMIC CHIP 0.047UF 10.00% 50V
C4369 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4370 1-126-967-11 ELECT 47UF 20.00% 50V
C4371 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4377 1-126-960-11 ELECT 1UF 20.00% 50V
C4518 1-162-638-11 CERAMIC CHIP 1UF 16V
C4519 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
< CONNECTOR >
CN4101 1-695-301-11 CONNECTOR, BOARD TO BOARD 40P
CN4500 *1-564-511-11 PLUG, CONNECTOR 8P
CN4502 *1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D4304 8-719-923-60 DIODE MTZJ-T-77-9.1
D4305 8-719-923-60 DIODE MTZJ-T-77-9.1
D4311 8-719-914-43 DIODE DAN202K-T-146
D4312 8-719-914-43 DIODE DAN202K-T-146
D4313 8-719-401-63 DIODE MA3062M-TX
< FERRITE BEAD >
FB4387 1-414-234-22 INDUCTOR CHIP 0UH
FB4388 1-414-234-22 INDUCTOR CHIP 0UH
FB4389 1-414-234-22 INDUCTOR CHIP 0UH
< IC >
IC4301 8-752-090-88 IC CXA2100AQ-TL
< COIL >
L4301 1-414-183-41 INDUCTOR 10UH
L4302 1-414-183-41 INDUCTOR 10UH
L4303 1-414-183-41 INDUCTOR 10UH
L4304 1-414-183-41 INDUCTOR 10UH
L4305 1-414-183-41 INDUCTOR 10UH
L4306 1-414-183-41 INDUCTOR 10UH
L4308 1-414-186-31 INDUCTOR 33UH
*A-1640-381-A E Board, Complete
E
D1
To Next Page
