109
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
L4309 1-414-186-31 INDUCTOR 33UH
< TRANSISTOR >
Q4304 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q4307 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q4308 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q4309 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q4310 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q4311 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q4312 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q4313 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q4315 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q4316 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
Q4317 8-729-900-53 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R4301 1-216-025-91 RES-CHIP 100 5% 1/10W
R4302 1-216-025-91 RES-CHIP 100 5% 1/10W
R4303 1-216-025-91 RES-CHIP 100 5% 1/10W
R4304 1-216-025-91 RES-CHIP 100 5% 1/10W
R4305 1-216-025-91 RES-CHIP 100 5% 1/10W
R4306 1-216-025-91 RES-CHIP 100 5% 1/10W
R4307 1-216-045-00 RES-CHIP 680 5% 1/10W
R4308 1-216-045-00 RES-CHIP 680 5% 1/10W
R4309 1-216-045-00 RES-CHIP 680 5% 1/10W
R4313 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R4314 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R4331 1-216-073-00 RES-CHIP 10K 5% 1/10W
R4332 1-216-073-00 RES-CHIP 10K 5% 1/10W
R4333 1-216-073-00 RES-CHIP 10K 5% 1/10W
R4334 1-216-025-91 RES-CHIP 100 5% 1/10W
R4335 1-216-025-91 RES-CHIP 100 5% 1/10W
R4336 1-216-025-91 RES-CHIP 100 5% 1/10W
R4337 1-216-025-91 RES-CHIP 100 5% 1/10W
R4339 1-216-049-91 RES-CHIP 1K 5% 1/10W
R4340 1-216-111-00 RES-CHIP 390K 5% 1/10W
R4341 1-216-295-91 SHORT 0
R4343 1-216-025-91 RES-CHIP 100 5% 1/10W
R4344 1-216-025-91 RES-CHIP 100 5% 1/10W
R4345 1-216-677-11 METAL CHIP 12K 0.5% 1/10W
R4346 1-216-681-11 METAL CHIP 18K 0.5% 1/10W
R4347 1-216-025-91 RES-CHIP 100 5% 1/10W
R4348 1-216-025-91 RES-CHIP 100 5% 1/10W
R4350 1-216-025-91 RES-CHIP 100 5% 1/10W
R4354 1-216-675-91 METAL CHIP 10K 0.5% 1/10W
R4355 1-216-009-91 RES-CHIP 22 5% 1/10W
R4356 1-216-009-91 RES-CHIP 22 5% 1/10W
R4357 1-216-009-91 RES-CHIP 22 5% 1/10W
R4358 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R4359 1-216-041-00 RES-CHIP 470 5% 1/10W
R4360 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R4361 1-216-133-00 RES-CHIP 3.3M 5% 1/10W
R4363 1-216-025-91 RES-CHIP 100 5% 1/10W
R4365 1-216-025-91 RES-CHIP 100 5% 1/10W
R4366 1-216-025-91 RES-CHIP 100 5% 1/10W
R4367 1-216-025-91 RES-CHIP 100 5% 1/10W
R4370 1-216-089-91 RES-CHIP 47K 5% 1/10W
R4371 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R4372 1-216-049-91 RES-CHIP 1K 5% 1/10W
R4373 1-216-073-00 RES-CHIP 10K 5% 1/10W
R4374 1-216-049-91 RES-CHIP 1K 5% 1/10W
R4375 1-216-049-91 RES-CHIP 1K 5% 1/10W
R4376 1-216-049-91 RES-CHIP 1K 5% 1/10W
R4377 1-216-049-91 RES-CHIP 1K 5% 1/10W
R4378 1-216-101-00 RES-CHIP 150K 5% 1/10W
R4379 1-216-091-00 RES-CHIP 56K 5% 1/10W
R4380 1-216-073-00 RES-CHIP 10K 5% 1/10W
R4381 1-216-125-00 RES-CHIP 1.5M 5% 1/10W
R4382 1-216-073-00 RES-CHIP 10K 5% 1/10W
R4383 1-216-089-91 RES-CHIP 47K 5% 1/10W
R4384 1-216-025-91 RES-CHIP 100 5% 1/10W
R4387 1-216-031-00 RES-CHIP 180 5% 1/10W
R4388 1-216-031-00 RES-CHIP 180 5% 1/10W
R4389 1-216-031-00 RES-CHIP 180 5% 1/10W
R4394 1-216-025-91 RES-CHIP 100 5% 1/10W
R4395 1-216-295-91 SHORT 0
R4396 1-216-295-91 SHORT 0
R4398 1-216-025-91 RES-CHIP 100 5% 1/10W
R4399 1-216-025-91 RES-CHIP 100 5% 1/10W
R4401 1-216-107-00 RES-CHIP 270K 5% 1/10W
R4507 1-216-129-00 RES-CHIP 2.2M 5% 1/10W
R4518 1-216-025-91 RES-CHIP 100 5% 1/10W
R4519 1-216-073-00 RES-CHIP 10K 5% 1/10W
R4520 1-216-295-91 SHORT 0
R4521 1-216-295-91 SHORT 0
R4522 1-216-073-00 RES-CHIP 10K 5% 1/10W
< CRYSTAL >
X4300 1-767-127-11 VIBRATOR, CERAMIC
E
