Sony FD Trinitron KV-29LS40B - Page 40

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 40 -
C1230 1-163-001-11 CERAMIC CHIP 220PF 10.00% 50V
C1232 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C1235 1-126-960-11 ELECT 1UF 20.00% 50V
C1236 1-126-960-11 ELECT 1UF 20.00% 50V
< CONNECTOR >
CN001 * 1-816-976-51 PLUG, CONNECTOR 5P
CN003 * 1-816-978-51 PLUG, CONNECTOR 7P
CN405 * 1-816-978-51 PLUG, CONNECTOR 7P
CN406 * 1-816-979-51 PLUG, CONNECTOR 8P
CN501 1-580-798-11 CONNECTOR PIN (DY)
CN506 1-695-915-11 TAB (CONTACT)
CN508 * 1-816-976-51 PLUG, CONNECTOR 5P
CN509 1-695-915-11 TAB (CONTACT)
CN510 1-691-771-11 PLUG (MICRO CONNECTOR) 9P
CN602 £ 1-508-765-13 PIN, CONNECTOR (5MM PITCH) 3P
CN603 £ * 1-508-786-00 PIN, CONNECTOR (5MM PITCH) 2P
CN605 £ * 1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN606 £ * 1-695-292-11 PIN, CONNECTOR (POWER)
CN1200 * 1-816-977-51 PLUG, CONNECTOR 6P
CN1201 * 1-816-975-51 PLUG, CONNECTOR 4P
< DIODE >
D001 8-719-069-55 DIODE UDZSTE-175.6B
D002 8-719-069-55 DIODE UDZSTE-175.6B
D003 8-719-109-69 DIODE RD3.6ESB2
D005 8-719-929-15 DIODE HZS9.1NB2
D006 8-719-109-89 DIODE RD5.6ESB2
D007 8-719-069-55 DIODE UDZSTE-175.6B
D008 8-719-074-43 DIODE BAS316-115
D010 8-719-074-43 DIODE BAS316-115
D011 8-719-074-43 DIODE BAS316-115
D013 8-719-109-69 DIODE RD3.6ESB2
D014 1-216-295-91 SHORT CHIP 0
D018 8-719-109-69 DIODE RD3.6ESB2
D022 8-719-069-55 DIODE UDZSTE-175.6B
D101 6-500-159-01 DIODE MA8330-M-TX
D107 8-719-069-55 DIODE UDZSTE-175.6B
D207 6-500-028-01 DIODE MM3Z9V1ST1
D210 8-719-069-55 DIODE UDZSTE-175.6B
D211 6-500-028-01 DIODE MM3Z9V1ST1
D212 8-719-914-43 DIODE DAN202K
D235 8-719-069-55 DIODE UDZSTE-175.6B
D236 6-500-028-01 DIODE MM3Z9V1ST1
D403 8-719-069-55 DIODE UDZSTE-175.6B
D404 8-719-109-89 DIODE RD5.6ESB2
D420 8-719-069-55 DIODE UDZSTE-175.6B
D424 6-500-028-01 DIODE MM3Z9V1ST1
D501 8-719-979-85 DIODE EGP20G
D502 8-719-081-90 DIODE PDZ22B-115
D1 A
D503 8-719-069-55 DIODE UDZSTE-175.6B
D504 8-719-074-43 DIODE BAS316-115
D505 8-719-081-97 DIODE MMDL914T1
D506 6-500-106-01 DIODE PG4003T/B
D507 8-719-070-59 DIODE PDZ6.8B-115
D512 8-719-302-43 DIODE EL1Z
D513 8-719-979-85 DIODE EGP20G
D514 8-719-979-85 DIODE EGP20G
D534 8-719-302-43 DIODE EL1Z
D535 8-719-908-03 DIODE GP08D
D536 6-500-367-01 DIODE BY228RAS20-10
D537 8-719-070-62 DIODE PDZ9.1B-115
D538 8-719-908-03 DIODE GP08D
D539 8-719-312-10 DIODE RU4AM-T3
D540 6-500-106-01 DIODE PG4003T/B
D541 1-216-295-91 SHORT CHIP 0
D573 8-719-082-00 DIODE MM3Z4V7T1
D601 8-719-510-53 DIODE D4SB60L
D602 8-719-911-19 DIODE 1SS119-25
D604 8-719-083-94 DIODE FUF4005
D608 6-500-175-01 DIODE 1E3-TB
D610 8-719-110-41 DIODE RD15ESB2
D611 8-719-991-33 DIODE 1SS133T-77
D612 8-719-991-33 DIODE 1SS133T-77
D613 8-719-911-19 DIODE 1SS119-25
D614 6-500-465-01 DIODE G2SBA60L-5700
D618 8-719-312-92 DIODE RK14V1
D619 8-719-312-92 DIODE RK14V1
D620 8-719-109-85 DIODE RD5.1ESB2
D621 8-719-109-89 DIODE RD5.6ESB2
D623 8-719-911-19 DIODE 1SS119-25
D625 6-500-246-01 DIODE FBIU4D7M1-B-4
D627 6-500-175-01 DIODE 1E3-TB
D628 8-719-083-49 DIODE P6KE200ASY
D629 8-719-083-94 DIODE FUF4005
D631 8-719-921-63 DIODE MTZJ-7.5B
D632 6-500-175-01 DIODE 1E3-TB
D633 8-719-109-69 DIODE RD3.6ESB2
D638 6-500-069-01 DIODE FMW-2109LF654
D640 8-719-921-63 DIODE MTZJ-7.5B
D1204 8-719-069-55 DIODE UDZSTE-175.6B
D1230 8-719-074-43 DIODE BAS316-115
< FERRITE BEAD >
FB410 1-414-760-21 FERRITE 0UH
FB411 1-414-760-21 FERRITE 0UH
FB412 1-414-760-21 FERRITE 0UH
FB601 1-469-578-11 FERRITE 1.1UH
FB602 1-469-578-11 FERRITE 1.1UH
