Sony FD Trinitron KV-29LS40B - Page 41

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 41 -
L446 1-216-295-91 SHORT CHIP 0
L448 1-216-295-91 SHORT CHIP 0
L501 1-414-187-11 INDUCTOR 47UH
L502 1-412-529-11 INDUCTOR 22UH
L503 1-412-521-31 INDUCTOR 4.7UH
L504 1-535-303-00 LEAD, JUMPER (5.0MM)
L505 1-412-542-41 INDUCTOR 270UH
L507 1-412-533-21 INDUCTOR 47UH
L532 1-412-553-11 INDUCTOR 3.3MH
L533 1-406-989-21 INDUCTOR 10MH
L534 1-216-025-11 RES-CHIP 100 5% 1/10W
L535 1-419-633-21 INDUCTOR 10MH
L601 1-408-603-31 INDUCTOR 10UH
L602 1-408-611-31 INDUCTOR 47UH
L603 1-535-303-00 LEAD, JUMPER (5.0MM)
L1201 1-535-303-00 LEAD, JUMPER (5.0MM)
L1203 1-535-303-00 LEAD, JUMPER (5.0MM)
< PHOTOCOUPLER >
PH601 £ 8-749-010-64 PHOTO COUPLER PC123F2
< PROTECTOR MODULE >
PS1201 £ 1-533-597-31 IC LINK 5A 90V
< TRANSISTOR >
Q013 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q049 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q202 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q203 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q212 8-729-422-33 TRANSISTOR 2SD601A-Q-TX
Q401 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q409 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q411 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q532 8-729-053-33 TRANSISTOR IRF614-037
Q533 6-550-669-01 TRANSISTOR ST2310DHI
Q535 8-729-053-33 TRANSISTOR IRF614-037
Q570 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q601 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q602 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q603 8-729-037-17 TRANSISTOR KRA104M-AT
Q604 8-729-036-60 TRANSISTOR KRC104M-AT
Q606 6-550-591-01 TRANSISTOR 2SK2543(LBS2SONY)
Q607 6-550-591-01 TRANSISTOR 2SK2543(LBS2SONY)
Q608 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q609 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q1230 8-729-027-56 TRANSISTOR DTC143TKA-T146
Q1231 8-729-027-56 TRANSISTOR DTC143TKA-T146
Q1232 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q1233 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
F4 A
FB603 1-412-911-11 FERRITE 0UH
FB604 1-469-578-11 FERRITE 1.1UH
FB605 1-469-578-11 FERRITE 1.1UH
FB606 £ 1-412-911-11 FERRITE 0UH
FB607 £ 1-412-911-11 FERRITE 0UH
< FILTER >
FL201 1-239-803-11 FILTER, EMI
< IC >
IC001 6-702-097-02 IC TDA9394H/N1/5/1031
IC004 8-759-675-65 IC M24C08-WMN6T(A)
IC201 6-700-411-02 IC MSP3411G-PP-B8V3
IC401 8-759-665-11 IC LM393DT
IC501 8-759-696-71 IC STV9379A
IC531 6-705-208-01 IC LM393DT
IC601 8-759-670-30 IC MCZ3001D
IC602 8-749-016-19 IC SE135N-LF4
IC603 6-702-992-01 IC TA78M08S
IC604 8-759-648-20 IC L7805CV/LSY
IC608 8-759-591-02 IC L78L33ABZ-AP
IC609 8-759-468-89 IC TOP209P
IC1201 8-759-831-57 IC TDA7495S
< SOCKET >
J401 * 1-766-296-41 CONNECTOR, DUAL SCART
J404 1-793-987-11 JACK, PIN 2P
< COIL >
L001 1-408-611-31 INDUCTOR 47UH
L004 1-408-611-31 INDUCTOR 47UH
L006 1-408-611-31 INDUCTOR 47UH
L027 1-216-295-91 SHORT CHIP 0
L101 1-412-534-31 INDUCTOR 56UH
L102 1-408-611-31 INDUCTOR 47UH
L103 1-412-002-31 INDUCTOR 4.7UH
L104 1-412-002-31 INDUCTOR 4.7UH
L201 1-535-303-00 LEAD, JUMPER (5.0MM)
L203 1-408-602-31 INDUCTOR 8.2UH
L205 1-408-591-11 INDUCTOR 1UH
L206 1-535-303-00 LEAD, JUMPER (5.0MM)
L207 1-408-591-11 INDUCTOR 1UH
L401 1-410-993-42 INDUCTOR 1UH
L403 1-410-993-42 INDUCTOR 1UH
L404 1-410-993-42 INDUCTOR 1UH
L405 1-535-303-00 LEAD, JUMPER (5.0MM)
L406 1-535-303-00 LEAD, JUMPER (5.0MM)
L410 1-216-025-11 RES-CHIP 100 5% 1/10W
L430 1-412-002-31 INDUCTOR 4.7UH
