REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 63 -
VM
C5853 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
C5868 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
< CONNECTOR >
CN1001 * 1-766-296-41 CONNECTOR, DUAL SCART
< RESISTOR >
R5300 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R5303 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R5318 1-208-818-11 METAL CHIP 33K 0.5% 1/10W
R5327 1-243-525-11 METAL OXIDE 33 5% 3W
R5334 1-208-834-11 METAL CHIP 150K 0.5% 1/10W
R5335 1-208-824-11 METAL CHIP 56K 0.5% 1/10W
R5340 1-216-049-11 RES-CHIP 1K 5% 1/10W
R5400 1-216-849-11 METAL CHIP 220K 5% 1/10W
R5407 1-216-857-11 METAL CHIP 1M 5% 1/10W
R5410 1-216-665-11 METAL CHIP 3.9K 0.5% 1/10W
R5417 1-216-665-11 METAL CHIP 3.9K 0.5% 1/10W
R5803 NOT FITTED
R5877 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5878 1-216-049-11 RES-CHIP 1K 5% 1/10W
R5883 1-216-857-11 METAL CHIP 1M 5% 1/10W
R5890 NOT FITTED
R5891 NOT FITTED
R5893 NOT FITTED
R5894 NOT FITTED
R5896 NOT FITTED
R5897 NOT FITTED
A Board Variant Parts KV28CS70B
< FILTER >
SF1003 1-767-083-11 FILTER, SURFACE WAVE
< TUNER >
TU1001 8-598-623-10 TUNER, FSS BTP-AC421
A Board Variant Parts KV28CS70E
< FILTER >
SF1003 NOT FITTED
< TUNER >
TU1001 8-598-623-10 TUNER, FSS BTP-AC421
A Board Variant Parts KV28CS70U
< FILTER >
SF1003 NOT FITTED
R7098 1-216-803-11 METAL CHIP 33 5% 1/10W
< FILTER >
SF1001 1-795-617-11 SAW FILTER
< CRYSTAL >
X1001 1-767-704-11 VIBRATOR, CRYSTAL
X2000 1-760-628-11 VIBRATOR, CRYSTAL
X3200 1-781-946-21 VIBRATOR, CRYSTAL
X5800 1-767-127-11 VIBRATOR, CERAMIC
A Board Variant Parts KV28CS70
< CAPACITOR >
C5320 1-129-716-00 FILM 0.015UF 5.00% 630V
C5321 1-136-347-11 FILM 0.0047UF 5.00% 630V
C5853 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C5868 1-163-129-00 CERAMIC CHIP 330PF 5.00% 50V
< CONNECTOR >
CN1001 * 1-766-296-21 CONNECTOR, DUAL SCART
< RESISTOR >
R5300 1-218-873-11 METAL CHIP 12K 0.5% 1/10W
R5303 NOT FITTED
R5318 1-208-806-11 METAL CHIP 10K 0.5% 1/10W
R5327 NOT FITTED
R5334 1-218-901-11 METAL CHIP 180K 0.5% 1/10W
R5335 1-208-818-11 METAL CHIP 33K 0.5% 1/10W
R5340 1-216-057-11 RES-CHIP 2.2K 5% 1/10W
R5400 1-216-848-11 METAL CHIP 180K 5% 1/10W
R5407 1-216-854-11 METAL CHIP 560K 5% 1/10W
R5410 1-208-798-11 METAL CHIP 4.7K 0.5% 1/10W
R5417 1-208-798-11 METAL CHIP 4.7K 0.5% 1/10W
R5803 1-216-861-11 METAL CHIP 2.2M 5% 1/10W
R5877 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5878 1-218-844-11 METAL CHIP 750 0.5% 1/10W
R5883 1-216-861-11 METAL CHIP 2.2M 5% 1/10W
R5890 1-218-823-11 METAL CHIP 100 0.5% 1/10W
R5891 1-218-903-11 METAL CHIP 220K 0.5% 1/10W
R5893 1-216-845-11 METAL CHIP 100K 5% 1/10W
R5894 1-218-823-11 METAL CHIP 100 0.5% 1/10W
R5896 1-218-903-11 METAL CHIP 220K 0.5% 1/10W
R5897 1-218-823-11 METAL CHIP 100 0.5% 1/10W
A Board Variant Parts KV-32CS70
< CAPACITOR >
C5320 1-129-817-00 FILM 0.022UF 5.00% 630V
C5321 NOT FITTED
