Sony FD Trinitron KV-32CS70B - VM, D, G, M, H6 Board Parts Lists

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 64 -
< TUNER >
TU1001 8-598-624-10 TUNER, FSS BTP-AU621
A Board Variant Parts KV32CS70B
< FILTER >
SF1003 1-767-083-11 FILTER, SURFACE WAVE
< TUNER >
TU1001 8-598-623-10 TUNER, FSS BTP-AC421
A Board Variant Parts KV32CS70E
< FILTER >
SF1003 NOT FITTED
< TUNER >
TU1001 8-598-623-10 TUNER, FSS BTP-AC421
A Board Variant Parts KV32CS70K
< FILTER >
SF1003 NOT FITTED
< TUNER >
TU1001 8-598-623-10 TUNER, FSS BTP-AC421
A Board Variant Parts KV32CS70U
< FILTER >
SF1003 NOT FITTED
< TUNER >
TU1001 8-598-624-10 TUNER, FSS BTP-AU621
* A-1071-321-A VM Board Complete (KV-28CS70)
* A-1055-723-A VM Board Complete (KV-32CS70)
VM Board Common Parts
4-382-854-01 SCREW (M3X8), P, SW (+)
< CAPACITOR >
C7401 1-126-935-11 ELECT 470UF 20.00% 16V
C7403 1-104-655-91 ELECT 470UF 20.00% 6.3V
C7404 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C7405 1-126-933-11 ELECT 100UF 20.00% 16V
C7406 1-104-655-91 ELECT 470UF 20.00% 6.3V
VM
C7407 1-107-364-11 MYLAR 0.01UF 10.00% 200V
C7408 1-107-364-11 MYLAR 0.01UF 10.00% 200V
C7409 1-107-649-11 ELECT 2.2UF 20.00% 250V
C7410 1-130-471-00 MYLAR 0.001UF 5.00% 50V
C7411 1-130-471-00 MYLAR 0.001UF 5.00% 50V
C7412 1-126-935-11 ELECT 470UF 20.00% 16V
C7413 1-126-935-11 ELECT 470UF 20.00% 16V
C7414 1-107-652-11 ELECT 10UF 20.00% 250V
C7415 1-107-363-91 MYLAR 0.0068UF 10.00% 200V
C7418 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C7421 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C7501 1-130-495-00 MYLAR 0.1UF 5.00% 50V
< CONNECTOR >
CN7442 * 1-564-510-11 PLUG, CONNECTOR 7P
CN7443 * 1-564-506-11 PLUG, CONNECTOR 3P
CN7444 * 1-770-747-11 CONNECTOR, BOARD TO BOARD 12P
CN7501 * 1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D7400 8-719-991-33 DIODE 1SS133T-77
D7401 8-719-991-33 DIODE 1SS133T-77
D7402 1-535-303-00 LEAD, JUMPER (5.0MM)
D7403 8-719-991-33 DIODE 1SS133T-77
D7404 8-719-991-33 DIODE 1SS133T-77
D7405 8-719-924-11 DIODE MTZJ-T-77-22
D7406 8-719-924-11 DIODE MTZJ-T-77-22
< FERRITE BEAD >
FB7400 1-535-303-00 LEAD, JUMPER (5.0MM)
FB7401 1-535-303-00 LEAD, JUMPER (5.0MM)
< COIL >
L7400 1-414-934-21 INDUCTOR 10UH
L7402 1-414-934-21 INDUCTOR 10UH
L7403 1-414-934-21 INDUCTOR 10UH
< TRANSISTOR >
Q7400 8-729-010-29 TRANSISTOR MSD601-RST1
Q7401 8-729-010-29 TRANSISTOR MSD601-RST1
Q7402 8-729-010-29 TRANSISTOR MSD601-RST1
Q7403 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q7404 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q7405 8-729-026-39 TRANSISTOR 2SA933AS-QT
Q7406 8-729-045-05 TRANSISTOR 2SA2005
Q7407 8-729-045-04 TRANSISTOR 2SC5511
Q7408 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q7409 8-729-010-29 TRANSISTOR MSD601-RST1
