SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• CAPACITORS
PF : µµ F
• There are some cases the reference number on one board
overlaps on the other board. Therefore, when ordering
parts by the reference number, please include the board
name.
When indicating parts by reference number,
please include the board name.
The components identified by
shading and mark
! are criti-
cal for safety.
Replace only with part number
specified.
• Items marked " * " are not stocked since they are seldom
required for routine service. Some delay should be
anticipated when ordering these items.
• All variable and adjustable resistors have characteristic
curve B, unless otherwise noted.
RESISTORS
• All resistors are in ohms
• F : nonflammable
*A-1135-818-A B BOARD, COMPLETE
*********************
<CAPACITOR>
C301 1-124-584-00 ELECT 100MF 20% 6.3V
C302 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C303 1-163-257-11 CERAMIC CHIP 180PF 5% 50V
C304 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C305 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C306 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C307 1-135-181-21 TANTAL. CHIP 4.7MF 20% 6.3V
C308 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C309 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C310 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C312 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C313 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C314 1-135-181-21 TANTAL. CHIP 4.7MF 20% 6.3V
C401 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C402 1-124-259-11 ELECT 4.7MF 20% 35V
C403 1-104-847-11 TANTAL. CHIP 22MF 20% 4V
C404 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C405 1-126-153-11 ELECT 22MF 20% 6.3V
C406 1-126-153-11 ELECT 22MF 20% 6.3V
C407 1-124-589-11 ELECT 47MF 20% 6.3V
C408 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C409 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C410 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C411 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C412 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C413 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C414 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C415 1-124-584-00 ELECT 100MF 20% 6.3V
C416 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C418 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C419 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C420 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C421 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C422 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C423 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C424 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C425 1-135-210-11 TANTAL. CHIP 4.7MF 20% 10V
C427 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C428 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C429 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C430 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C434 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C501 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C502 1-124-584-00 ELECT 100MF 20% 10V
C504 1-135-259-11 TANTAL. CHIP 10MF 20% 6.3V
C505 1-124-584-00 ELECT 100MF 20% 6.3V
C506 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C507 1-164-222-11 CERAMIC CHIP 0.22MF 25V
<CONNECTOR>
CN502 1-770-606-11 CONNECTOR, BOARD TO BOARD 12P
<DIODE>
D301 8-719-404-50 DIODE MA111-TX
D401 8-719-059-51 DIODE MA3J142E0LSO
D402 8-719-404-50 DIODE MA111-TX
D403 8-719-404-50 DIODE MA111-TX
D404 8-719-404-50 DIODE MA111-TX
D405 8-719-404-50 DIODE MA111-TX
D406 8-719-018-04 DIODE MA8240-TX
D501 8-719-800-76 DIODE 1SS226
D502 8-719-800-76 DIODE 1SS226
<IC>
IC301 8-759-332-45 IC M52045FP
IC401 8-759-368-68 IC A71-2980
IC501 8-759-046-84 IC NJM2070M
<JACK>
J501 1-563-282-11 JACK, SMALL TYPE
<COIL>
L501 1-412-935-11 INDUCTOR 0.47UH
<TRANSISTOR>
Q302 8-729-424-76 TRANSISTOR UN2210
Q303 8-729-422-37 TRANSISTOR 2SB709A-R
Q401 8-729-422-29 TRANSISTOR 2SD601A-S
Q402 8-729-402-32 TRANSISTOR 2SD1819A-R
Q403 8-729-902-99 TRANSISTOR DTC114TK
Q406 8-729-427-74 TRANSISTOR XP4601
Q407 8-729-427-74 TRANSISTOR XP4601
Q408 8-729-420-44 TRANSISTOR UN5210
<RESISTOR>
R301 1-216-085-00 RES,CHIP 33K 5% 1/10W
R302 1-216-091-00 RES,CHIP 56K 5% 1/10W
R303 1-216-041-00 RES,CHIP 470 5% 1/10W
R304 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R305 1-216-077-00 RES,CHIP 15K 5% 1/10W
R307 1-216-091-00 RES,CHIP 56K 5% 1/10W
R308 1-216-077-00 RES,CHIP 15K 5% 1/10W
R309 1-216-001-00 RES,CHIP 10 5% 1/10W
R310 1-216-093-91 RES,CHIP 68K 5% 1/10W
R311 1-216-101-00 RES,CHIP 150K 5% 1/10W
R312 1-216-043-91 RES,CHIP 560 5% 1/10W
B
To Next Page
