Sony FDL-22 - Page 18

REF. NO. PART NO. DESCRIPTION REMARK
------------ ------------- ------------------- -------------
REF. NO. PART NO. DESCRIPTION REMARK
------------ ------------- ------------------- -------------
The components identified by
shading and mark
! are criti-
cal for safety.
Replace only with part number
specified.
– 29 –
-------------------------------------------------------------------------------------------------------------------------------
-------------------------------------------------------------------------------------------------------------------------------
-------------------
R313 1-216-113-00 RES,CHIP 470K 5% 1/10W
R314 1-216-097-91 RES,CHIP 100K 5% 1/10W
R315 1-216-081-00 RES,CHIP 22K 5% 1/10W
R316 1-216-109-00 RES,CHIP 330K 5% 1/10W
R317 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R318 1-216-687-11 METAL CHIP 33K 0.50% 1/10W
R320 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R322 1-216-695-11 METAL CHIP 68K 0.50% 1/10W
R323 1-216-129-00 RES,CHIP 2.2M 5% 1/10W
R324 1-216-073-00 RES,CHIP 10K 5% 1/10W
R325 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R327 1-216-295-91 SHORT 0
R401 1-216-099-00 RES,CHIP 120K 5% 1/10W
R402 1-216-095-00 RES,CHIP 82K 5% 1/10W
R403 1-216-017-91 RES,CHIP 47 5% 1/10W
R404 1-216-083-00 RES,CHIP 27K 5% 1/10W
R405 1-216-093-91 RES,CHIP 68K 5% 1/10W
R406 1-216-035-00 RES,CHIP 270 5% 1/10W
R407 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R408 1-216-660-11 METAL CHIP 2.4K 0.50% 1/10W
R409 1-216-093-91 RES,CHIP 68K 5% 1/10W
R410 1-216-689-11 RES,CHIP 39K 5% 1/10W
R411 1-216-121-91 RES,CHIP 1M 5% 1/10W
R412 1-216-081-00 RES,CHIP 22K 5% 1/10W
R413 1-216-081-00 RES,CHIP 22K 5% 1/10W
R414 1-216-081-00 RES,CHIP 22K 5% 1/10W
R415 1-216-081-00 RES,CHIP 22K 5% 1/10W
R416 1-216-001-00 RES,CHIP 10 5% 1/10W
R417 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R418 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R419 1-216-073-00 RES,CHIP 10K 5% 1/10W
R420 1-216-049-91 RES,CHIP 1K 5% 1/10W
R421 1-216-073-00 RES,CHIP 10K 5% 1/10W
R422 1-216-073-00 RES,CHIP 10K 5% 1/10W
R423 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R424 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R427 1-216-049-91 RES,CHIP 1K 5% 1/10W
R428 1-216-083-00 RES,CHIP 27K 5% 1/10W
R429 1-216-025-91 RES,CHIP 100 5% 1/10W
R430 1-216-025-91 RES,CHIP 100 5% 1/10W
R431 1-216-025-91 RES,CHIP 100 5% 1/10W
R432 1-216-025-91 RES,CHIP 100 5% 1/10W
R436 1-216-073-00 RES,CHIP 10K 5% 1/10W
R447 1-216-073-00 RES,CHIP 10K 5% 1/10W
R501 1-216-308-00 RES,CHIP 4.7 5% 1/10W
R502 1-216-142-00 RES,CHIP 4.7 5% 1/8W
R503 1-216-142-00 RES,CHIP 4.7 5% 1/8W
R504 1-216-041-00 RES,CHIP 470 5% 1/10W
R505 1-216-041-00 RES,CHIP 470 5% 1/10W
R506 1-216-039-00 RES,CHIP 390 5% 1/10W
R509 1-216-099-00 RES,CHIP 120K 5% 1/10W
R510 1-216-073-00 RES,CHIP 10K 5% 1/10W
<RESISTOR BLOCK>
RB401 1-233-788-11 RES, NETWORK 2.2K
RB402 1-233-788-11 RES, NETWORK 2.2K
RB403 1-233-788-11 RES, NETWORK 2.2K
RB404 1-233-788-11 RES, NETWORK 2.2K
RB405 1-233-788-11 RES, NETWORK 2.2K
<VARIABLE RESISTOR>
RV301 1-223-587-11 RES, ADJ, CARBON 22K
RV401 1-223-901-21 RES, VAR 50K
RV402 1-223-587-11 RES, ADJ, CARBON 22K
RV501 1-223-900-21 RES, VAR 10K
<CRYSTAL>
X301 1-567-505-41 OSCILLATOR, CRYSTAL
X401 1-760-601-21 VIBRATOR, CRYSTAL
*************************************************************
*A-1297-491-A A BOARD, COMPLETE
*********************
<CAPACITOR>
C001 1-124-259-11 ELECT 4.7MF 20% 16V
C002 1-126-153-11 ELECT 22MF 20% 6.3V
C003 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
C004 1-124-589-11 ELECT 47MF 20% 6.3V
C005 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C006 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C007 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C008 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C010 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C011 1-126-157-11 ELECT 10MF 20% 6.3V
C012 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C014 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C015 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C016 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C106 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C109 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C110 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C203 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C204 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C205 1-135-181-21 TANTAL. CHIP 4.7MF 20% 6.3V
C206 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C207 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C208 1-163-085-00 CERAMIC CHIP 2PF 0.25PF 50V
C209 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C210 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C211 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C212 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C213 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C215 1-124-589-11 ELECT 47MF 20% 6.3V
C216 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C218 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C219 1-135-145-11 TANTAL. CHIP 0.47MF 20% 25V
C220 1-135-149-21 TANTAL. CHIP 2.2MF 20% 6.3V
C222 1-135-259-11 TANTAL. CHIP 10MF 20% 6.3V
C223 1-135-145-11 TANTAL. CHIP 0.47MF 20% 25V
C224 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C225 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C226 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C227 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C228 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C234 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C235 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C601 1-124-584-00 ELECT 100MF 20% 10V
C603 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C604 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C605 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C610 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C611 1-124-261-00 ELECT 10MF 20% 50V
C612 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C613 1-127-561-11 ELECT 33MF 20% 10V
C614 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C615 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C616 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C617 1-124-584-00 ELECT 100MF 20% 6.3V
C619 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
AB
