REF. NO. PART NO. DESCRIPTION REMARK
------------ ------------- ------------------- -------------
REF. NO. PART NO. DESCRIPTION REMARK
------------ ------------- ------------------- -------------
The components identified by
shading and mark
! are criti-
cal for safety.
Replace only with part number
specified.
– 30 –
-------------------------------------------------------------------------------------------------------------------------------
-------------------------------------------------------------------------------------------------------------------------------
-------------------
<FILTER>
CF201 1-409-332-00 CERAMIC TRAP
CF202 1-760-642-11 DISCRIMINATOR, CERAMIC
CF203 1-577-559-21 FILTER, CERAMIC
<CONNECTOR>
CN201 *1-770-605-11 CONNECTOR, BOARD TO BOARD 12P
CN601 *1-770-590-11 PIN, CONNECTOR (PC BOARD)
<DIODE>
D001 8-719-801-78 DIODE 1SS184
D002 8-719-800-76 DIODE 1SS226
D601 8-719-421-82 DIODE MA8043-M
D602 8-719-027-72 DIODE MA199-(TX)
D603 8-719-048-98 DIODE RB160L-40TE25
D604 8-719-018-15 DIODE MA8360
D605 8-719-404-50 DIODE MA111-TX
<FUSE>
F601 ! 1-533-631-31 FUSE, MICRO
<IC>
IC001 8-759-332-43 IC AN5707NFAP
IC201 8-759-176-91 IC M51348AFP
<COIL>
L201 1-412-008-31 INDUCTOR CHIP 15UH
L205 1-410-992-11 INDUCTOR CHIP 0.82UH
L208 1-412-029-11 INDUCTOR CHIP 10UH
L601 1-412-031-11 INDUCTOR CHIP 47UH
<TRANSISTOR>
Q001 8-729-422-37 TRANSISTOR 2SB709A-R
Q002 8-729-402-84 TRANSISTOR XN4601
Q003 8-729-424-76 TRANSISTOR UN2210
Q004 8-729-424-38 TRANSISTOR UN2110
Q006 8-729-422-54 TRANSISTOR XN4215
Q007 8-729-424-45 TRANSISTOR UN211D-TX
Q201 8-729-031-37 TRANSISTOR 2SC3837KQ
Q202 8-729-422-37 TRANSISTOR 2SB709A-R
Q203 8-729-424-76 TRANSISTOR UN2210
Q601 8-729-422-29 TRANSISTOR 2SD601A-S
Q602 8-729-422-29 TRANSISTOR 2SD601A-S
Q603 8-729-421-15 TRANSISTOR 2SD1119-Q
Q610 8-729-422-37 TRANSISTOR 2SB709A-R
<RESISTOR>
R001 1-216-099-00 RES,CHIP 120K 5% 1/10W
R002 1-216-095-00 RES,CHIP 82K 5% 1/10W
R003 1-216-091-00 RES,CHIP 56K 5% 1/10W
R004 1-216-089-91 RES,CHIP 47K 5% 1/10W
R005 1-216-101-00 RES,CHIP 150K 5% 1/10W
R008 1-218-762-11 METAL CHIP 270K 0.50% 1/10W
R009 1-216-687-11 METAL CHIP 33K 0.50% 1/10W
R010 1-216-308-00 RES,CHIP 4.7 5% 1/10W
R011 1-216-073-00 RES,CHIP 10K 5% 1/10W
R012 1-216-109-00 RES,CHIP 330K 5% 1/10W
R013 1-216-091-00 RES,CHIP 56K 5% 1/10W
R014 1-216-689-11 RES,CHIP 39K 5% 1/10W
R015 1-216-073-00 RES,CHIP 10K 5% 1/10W
R016 1-216-689-11 RES,CHIP 39K 5% 1/10W
R017 1-216-079-00 RES,CHIP 18K 5% 1/10W
R018 1-216-097-91 RES,CHIP 100K 5% 1/10W
R019 1-216-107-00 RES,CHIP 270K 5% 1/10W
R020 1-216-113-00 RES,CHIP 470K 5% 1/10W
R021 1-216-097-91 RES,CHIP 100K 5% 1/10W
R022 1-216-089-91 RES,CHIP 47K 5% 1/10W
R024 1-216-089-91 RES,CHIP 47K 5% 1/10W
R029 1-216-041-00 RES,CHIP 470 5% 1/10W
R031 1-216-105-91 RES,CHIP 220K 5% 1/10W
R032 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R111 1-216-001-00 RES,CHIP 10 5% 1/10W
R201 1-216-045-00 RES,CHIP 680 5% 1/10W
R202 1-216-033-00 RES,CHIP 220 5% 1/10W
R205 1-216-097-91 RES,CHIP 100K 5% 1/10W
R206 1-216-045-00 RES,CHIP 680 5% 1/10W
R208 1-216-045-00 RES,CHIP 680 5% 1/10W
R209 1-216-055-00 RES,CHIP 1.8K 5% 1/10W
R210 1-216-085-00 RES,CHIP 33K 5% 1/10W
R212 1-216-037-00 RES,CHIP 330 5% 1/10W
R213 1-216-073-00 RES,CHIP 10K 5% 1/10W
R215 1-216-009-91 RES,CHIP 22 5% 1/10W
R216 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R217 1-216-039-00 RES,CHIP 390 5% 1/10W
R218 1-216-021-00 RES,CHIP 68 5% 1/10W
R219 1-216-039-00 RES,CHIP 390 5% 1/10W
R220 1-216-017-91 RES,CHIP 47 5% 1/10W
R221 1-216-049-91 RES,CHIP 1K 5% 1/10W
R222 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R223 1-216-049-91 RES,CHIP 1K 5% 1/10W
R224 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R225 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R226 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R228 1-216-073-00 RES,CHIP 10K 5% 1/10W
R229 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R230 1-216-001-00 RES,CHIP 10 5% 1/10W
R231 1-216-009-91 RES,CHIP 22 5% 1/10W
R240 1-216-073-00 RES,CHIP 10K 5% 1/10W
R241 1-216-103-00 RES,CHIP 180K 5% 1/10W
R242 1-216-041-00 RES,CHIP 470 5% 1/10W
R243 1-216-081-00 RES,CHIP 22K 5% 1/10W
R601 1-216-091-00 RES,CHIP 56K 5% 1/10W
R602 1-216-089-91 RES,CHIP 47K 5% 1/10W
R603 1-216-009-91 RES,CHIP 22 5% 1/10W
R604 1-216-037-00 RES,CHIP 330 5% 1/10W
R605 1-216-025-91 RES,CHIP 100 5% 1/10W
R606 1-216-295-91 SHORT 0
R608 1-216-091-00 RES,CHIP 56K 5% 1/10W
R610 1-216-025-91 RES,CHIP 100 5% 1/10W
R611 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R612 1-216-033-00 RES,CHIP 220 5% 1/10W
R613 1-216-043-91 RES,CHIP 560 5% 1/10W
R614 1-216-085-00 RES,CHIP 33K 5% 1/10W
R615 1-216-073-00 RES,CHIP 10K 5% 1/10W
R616 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
<VARIABLE RESISTOR>
RV001 1-223-588-11 RES, ADJ, CARBON 47K
RV002 1-223-588-11 RES, ADJ, CARBON 47K
RV003 1-223-598-11 RES, VAR, CARBON 100K
RV004 1-223-598-11 RES, VAR, CARBON 100K
RV201 1-223-583-11 RES, ADJ, CARBON 1K
RV601 1-223-581-11 RES, ADJ, CARBON 220
<SWITCH>
S001 1-571-532-21 SWITCH, TACTIL
S002 1-571-532-21 SWITCH, TACTIL
S601 1-762-368-11 SWITCH, SLIDE
