– 9 –
1. Receive a *signal. 2. Connect a *oscilloscope to *JL32. 3. Adjust waveform by *RV to be *Fig 3 or *Fig 4.
MEASUREMENT
POSITION
ADJUSTMENT
LOCATION
ILLUSTRATION AND SHAPE
AND NUMBER
ADJUSTMENT ITEM AND PROCEDURE
EQUIPMENT
AND SIGNAL
PHASE ADJUSTMENT
* Color-bar * Oscilloscope *JL32 (B)
*RV301
Small wize line
Fig 3.
Fig 4.
