Sony GN6UR - Set Part List

REF. NO
PART NO.
DESCRIPTION
XBR-55X950H
UCM
1 5-011-811-01 LABEL, SIDE TERMINAL (PCH)
•
2 1-005-629-11 C7L AC POWER CODE SETS (US)
•
3 - CARD COVER (LPCH)
-Not Applicable for America region-
4 5-009-195-11 REAR COVER (L PCH) A
•
5 1-004-512-11 SP ASSY,PZ25-25
•
6 1-004-509-11 SP-BOX ASSY,FY20 W30L-FA
•
7 1-004-509-21 SP-BOX ASSY,FY20 W30L-FB
•
8 5-009-258-21 BRACKET, WIFI(BNN)
•
9 1-005-419-11 WLAN/BT MODULE(11AC)
•
10 - BRACKET, TOP(BNN)
-Not Applicable for America region-
11 5-015-416-31 BRACKET SIDE (BNN) A
•
12 A-5011-896-A COMPL_SVC_BM3JT_UCM
•
13 1-006-110-12 G01-STATIC CONVERTER (TV)
•
14 5-018-060-01 SHEET, THERMAL (PCH G)
•
15 5-009-269-01 SHEET, INSULATION (BNN L)
•
15 5-009-269-11 SHEET, INSULATION (BNN L)
•
16
A-5016-209-A COMPL 20LD48A1_55
•
17 1-006-262-11 MOUNTED PWB E-T-CON (55)
•
18 A-5017-628-A P-MOD (YDAS055DNU02)(SERVICE)
•
19 5-009-352-11 STAND, L (L PCH) A
•
20 5-009-356-11 STAND, R (L PCH) A
•
21 5-009-894-11 STAND NECK (L PCH) A
•
SET PART LIST
30
SECTION 1
XBR-55X9*H
!
!
!
TOOLS & EQUIPMENTS
SECTION 1 SECTION 2 SECTION 3 SMART CORE
SYSSET
2020/07/1500:48:41(GMT+09:00)
