Sony GN6UR - Page 86

REF. NO PART NO.
DESCRIPTION
XBR-75X950H XBR-75X955H
UCM LA8
1
5-011-811-01 LABEL, SIDE TERMINAL (PCH)
• n/a
1
5-011-811-21 LABEL, SIDE TERMINAL (PCH)
n/a •
2
1-005-629-11 C7L AC POWER CODE SETS (US)
• n/a
2
1-839-695-12 POWER-SUPPLY CORD (WITH CONN.)
n/a •
3
- CARD COVER (3L PCH)
-Not Applicable for America region-
4
5-009-199-11 REAR COVER (3L PCH) A
• n/a
4
5-009-199-31 REAR COVER (3L PCH) A
n/a •
5
1-004-512-11 SP ASSY,PZ25-25
• •
6
1-004-511-11 SP-BOX ASSY,FY20 W30XL-A
• •
7
1-004-511-21 SP-BOX ASSY,FY20 W30XL-B
• •
8
5-009-258-21 BRACKET, WIFI(BNN)
• •
9
1-005-419-11 WLAN/BT MODULE(11AC)
• •
10
-
BRACKET, TOP(BNN)
-Not Applicable for America region-
11
5-015-416-31 BRACKET SIDE (BNN) A
• n/a
11
5-015-416-11 BRACKET SIDE (BNN) A
n/a •
12
A-5011-896-A COMPL_SVC_BM3JT_UCM
• n/a
12
A-5011-897-A COMPL_SVC_BM3JT_LA
n/a •
13
1-006-109-22 G03P - STATIC CONVERTER (TV)
• n/a
13
1-006-109-12 G03 - STATIC CONVERTER (TV)
n/a •
14
5-009-271-01 SHEET, INSULATION (BNN 3L)
• •
15
A-5016-211-B COMPL 20LD60A1_75
• •
16
1-006-266-11 MOUNTED PWB E-T-CON (75)
• •
17
A-5017-626-A P-MOD (YDAS075DNN02)(SERVICE)
• •
18
5-009-368-11 STAND, L (3L PCH) A
• •
19
5-009-372-11 STAND, R (3L PCH) A
• •
20
5-013-289-11 STAND NECK (3L PCH) A
• •
SET PART LIST
86
SECTION 3
XBR-75X9*H
TOOLS & EQUIPMENTS
SECTION 1 SECTION 2 SECTION 3 SMART CORE
!
!
!
!
!
SYSSET
2020/07/1500:48:41(GMT+09:00)
