Contents List:
Main LSIname
Model
Destination
Sequence Number
MAC
IP
IFCON IFCON Version
Bootloader Bootloader Version
Host Main Host Main Version
MicroBE MicroBE Version
Host Sub Host Sub Version
Middleware Middleware Version
ADSP ADSP Version
ADSP Coeff ADSP Coeff Version
2nd DSP 2nd DSP Version (not used)
IF Model
IF Dest
WLAN module Serial
WLAN module hw Version
WLAN module MAC Address
Drive Firm Revision
CD DIOP Delta IOP
DVD DIOP Delta IOP
BD DIOP Delta IOP
CD LD TIME LD Time
DVD LD TIME LD Time
BD LD TIME LD Time
16. Drive
This menu is used to operate the drive using drive-related diagnos-
tic and tools.
Screen 1: Selecting items under *Drive
Operation:
[
<
]/[
,
] Selects the category
[
m
]/[ ] Activate the selected category
[RETURN] Returns to the top menu of the service mode
[1] Drive OP data Write
[2] Servo Parameter Check Menu (Not used)
[3] Servo Signal Check Menu (Not used)
[4] S-Curve Check Menu (Not used)
[5] Readability Check Menu (Not used)
[6] OP Position Check Menu (Not used)
[7] OP Check Menu (Not used)
[8] Load Eject Aging (Not used)
[9] Spindle Control Check Menu (Not used)
[10] FA Test Mode (Not used)
Screen 2: To start OP data Write
Operation:
[ ] Starts
Screen 3: Show OP data Write result
Operation:
NG - USB is not fi nd
OK - OP data write
• Drive Test
For drive operating check. Service is only use Drive OP data write
to rewrite OP data after change of new CPU.
 Drive
[1] Drive OP data Write
 Drive OP data Write
Insert USB StorageDevice ...
Remove DISC and Close tray.
HELP: [ENT] [RET]
Disc : Load
Mode: 1
(Screen 1)
(Screen 2)
(Screen 3)
HELP: [ENT] [RET]

Drive OP data Write
Insert USB StorageDevice ...
Remove DISC and Close tray.
NG - USB is not find
OK - OP data write
[ENT] Start
[ENT] Start
 System Information
Sequence Number:
MAC:
IP:
Model:
Main LSIname:
Destination:
IF-con Block0 Version:
Bootloader Version:
Host Main Version:
MicroBE Version:
Host Sub Version:
Middleware Version:
ADSP Version:
ADSP Coeff Version:
HELP : [RET] [RIGHT]
(Screen 1)

System Information
CD DIOP:
DVD DIOP:
WLAN module hw version:
WLAN module MAC Address:
Drive Firm Revision:
WLAN module Serial:
IF_MODEL:
IF_DEST:
BD DIOP:
CD LD TIME:
DVD LD TIME:
BD LD TIME:
HELP : [RET] [LEFT]
(Screen 2)
