HBD-E190/E290/E490/E690
61
• IC Pin Function Descriptions
MB148 BOARD except (2/9), (8/9), (9/9) IC101 CXD90008G-AA (except Singapore, Taiwan, Thai and Chinese models) (BD DECODER)
MB148 BOARD except (2/9), (8/9), (9/9) IC101 CXD90008G-AB (Singapore, Taiwan, Thai and Chinese models) (BD DECODER)
Pin No. Pin Name I/O Description
A1 TRINC I Input of Tracking Signal (C)
A2 TRINA I Input of Tracking Signal (A)
A3 FPDOCD I Laser Power Monitor Input for CD APC / Differential negative input
A4 VWDC3O O Output Voltage 3 of Laser Diode Control in APC
A5 TXVN_0 I/O Ethernet TD -
A6 TXVN_1 I/O Ethernet RD -
A7 SPDIF I/O SPDIF digital audio output
A8 NO_USE - Not used
A9 NO_USE - Not used
A10
AOBCK
ALO
I/O Audio output bit clock
A11 NS_XTALI - 3.3V power for standby
A12 NO_USE - Not used
A13 CH2_M O HDMI TX data 2 differential pair (M)
A14 CH1_M O HDMI TX data 1 differential pair (M)
A15 CH0_M O HDMI TX data 0 differential pair (M)
A16 CLK_M O HDMI TX clock differential pair (M)
A17 NO_USE - Not used
A18 VDACG_OUT O DAC output
A19 CEC I/O HDMI CEC
A20 NO_USE - Not used
A21 RESET_ I Power on reset
A22
IF_SCK
VCLK
I/O VFD clock
A23
IF_SDO
VDATA
I/O VFD data
A24 SPLRCK I/O SPDIF input left-right clock
A25 SPMCLK I/O SPDIF input master clock
B1 INB I Input of Main Beam Signal (B)
B2 TRIND I Input of Tracking Signal (D)
B3 TRINB I Input of Tracking Signal (B)
B4 FVREF O Output of Voltage Reference
B5 TXVP_0 I/O Ethernet TD +
B6 TXVP_1 I/O Ethernet RD +
B7 REXT O External reference resistor
B8 NO_USE - Not used
B9 NO_USE - Not used
B10
AOMCL
ARO
I/O Audio output master clock
B11 NS_XTALO I 27MHz Crystal In
B12 NO_USE - Not used
B13 CH2_P O HDMI TX data 2 differential pair (P)
B14 CH1_P O HDMI TX data 1 differential pair (P)
B15 CH0_P O HDMI TX data 0 differential pair (P)
B16 CLK_P O HDMI TX clock differential pair (P)
B17 NO_USE - Not used
B18 VDACX_OUT O DAC output
B19 HDMISD I/O HDMI I2C data
B20 HDMISCK I/O HDMI I2C clock
B21 OPWRSB I/O Power Control
B22
NC
IR
I/O Infrared input
Ver. 1.1
