Sony HBD-E690 - IC Pin Function Descriptions - MB148 Board (F & G Chips); MB148 IC Pin Descriptions (F1-F25); MB148 IC Pin Descriptions (G1-G25)

HBD-E190/E290/E490/E690
64
Pin No. Pin Name I/O Description
F20 NO_USE - Not used
F21 DVCC33_IO - 3.3 V digital IO power
F22 NC (PD) - Not used
F23 NO_USE - Not used
F24 TMS I/O GPIO
F25 NC (PD) - Not used
G1 RFIP I Differential Input of AC Coupling RF SUM Signal (Positive)
G2 RFIN I Differential Input of AC Coupling RF SUM Signal (Negative)
G3 NO_USE - Not used
G4 NO_USE - Not used
G5 NO_USE - Not used
G6 NO_USE - Not used
G7 NO_USE - Not used
G8 NO_USE - Not used
G9 AVDD33_LD - Line driver 3.3 V analog power
G10 NO_USE - Not used
G11 AVDD12_REC - ADC analog power
G12 NO_USE - Not used
G13 NO_USE - Not used
G14 AVSS33_VDAC - Analog Ground
G15 NO_USE - Not used
G16 AVSS33_LDO - Analog ground for standby
G17 NO_USE - Not used
G18 NO_USE - Not used
G19 NO_USE - Not used
G20 DVCC33_IO - 3.3 V digital IO power
G21 XIF_CS I/O GPIO
G22 NO_USE - Not used
G23 TDO I/O JTAG ICE data out
G24 DIR_SDA I/O GPIO
G25 DIR_ERROR I/O GPIO
H1 RFIP2 I Differential Input of AC Coupling RF SUM Signal (Positive)
H2 RFIN2 I Differential Input of AC Coupling RF SUM Signal (Negative)
H3 V14 O Output of Voltage Reference (1.4 V)
H4 FOO O Focus servo output. PDM output of focus servo compensator.
H5 AGND12_1 - Analog Ground
H6 NO_USE - Not used
H7 AGND12_2 - Analog Ground
H8 NO_USE - Not used
H9 NO_USE - Not used
H10 NO_USE - Not used
H11 NO_USE - Not used
H12 NO_USE - Not used
H13 NO_USE - Not used
H14 DGND12_K - Digital ground
H15 NO_USE - Not used
H16 AVDD12_LDO - 1.2 V standby power
H17 NO_USE - Not used
H18 NO_USE - Not used
H19 NO_USE - Not used
H20 NO_USE - Not used
H21 DGND12_K - Digital ground
H22 XDIR_INT I/O GPIO
