Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E190/E290/E490/E690
8787
R3157 1-218-232-91 METAL CHIP 4.7 10% 1/2W
R3158 1-218-232-91 METAL CHIP 4.7 10% 1/2W
R3161 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3162 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3212 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3271 1-218-282-11 METAL CHIP 22 5% 1/2W
R3272 1-218-282-11 METAL CHIP 22 5% 1/2W
R3281 1-218-282-11 METAL CHIP 22 5% 1/2W
R3282 1-218-282-11 METAL CHIP 22 5% 1/2W
R3283 1-218-232-91 METAL CHIP 4.7 10% 1/2W
R3284 1-218-232-91 METAL CHIP 4.7 10% 1/2W
R3301 1-219-365-11 SHORT CHIP 0
R3311 1-219-365-11 SHORT CHIP 0
R3312 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3345 1-216-296-11 SHORT CHIP 0
R3348 1-216-864-11 SHORT CHIP 0
R3353 1-220-281-11 METAL CHIP 4.7K 5% 1/4W
R3354 1-220-281-11 METAL CHIP 4.7K 5% 1/4W
R3355 1-220-281-11 METAL CHIP 4.7K 5% 1/4W
R3356 1-220-281-11 METAL CHIP 4.7K 5% 1/4W
R3357 1-218-232-91 METAL CHIP 4.7 10% 1/2W
R3358 1-218-232-91 METAL CHIP 4.7 10% 1/2W
R3361 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3371 1-218-282-11 METAL CHIP 22 5% 1/2W
R3372 1-218-282-11 METAL CHIP 22 5% 1/2W
R3381 1-218-282-11 METAL CHIP 22 5% 1/2W
R3382 1-218-282-11 METAL CHIP 22 5% 1/2W
R3383 1-218-232-91 METAL CHIP 4.7 10% 1/2W
R3384 1-218-232-91 METAL CHIP 4.7 10% 1/2W
R3501 1-218-953-11 METAL CHIP 1K 5% 1/16W
R3502 1-218-953-11 METAL CHIP 1K 5% 1/16W
R3504 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R3505 1-218-990-81 SHORT CHIP 0
R3506 1-218-990-81 SHORT CHIP 0
R3507 1-208-675-11 METAL CHIP 470 0.5% 1/16W
R3543 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
R3544 1-216-864-11 SHORT CHIP 0
R3555 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3556 1-218-969-11 METAL CHIP 22K 5% 1/16W
R3557 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R3558 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R3559 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R3560 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3902 1-216-839-11 METAL CHIP 33K 5% 1/10W
R3903 1-216-839-11 METAL CHIP 33K 5% 1/10W
R3904 1-216-839-11 METAL CHIP 33K 5% 1/10W
R3905 1-216-839-11 METAL CHIP 33K 5% 1/10W
< COMPOSITION CIRCUIT BLOCK >
RB3001 1-234-372-11 RES, NETWORK 100 (1005X4)
RB3002 1-234-372-11 RES, NETWORK 100 (1005X4)
RB3003 1-239-409-11 RES, CHIP NETWORK 47 (3216)
RB3102 1-233-575-11 RES, CHIP NETWORK 22 (3216)
RB3302 1-233-575-11 RES, CHIP NETWORK 22 (3216)
RB3303 1-234-381-11 RES, NETWORK 100K (1005X4)
RB3304 1-234-381-11 RES, NETWORK 100K (1005X4)
RB3305 1-234-381-11 RES, NETWORK 100K (1005X4)
< TERMINAL >
TB3401 1-780-452-11 TERMINAL BOARD (SPEAKER) 2P
(SPEAKERS SUR R/SUR L)
TB3451 1-780-951-11 TERMINAL BOARD (SPEAKER) 4P
(SPEAKERS FRONT R/FRONT L/SUBWOOFER/
CENTER)
************************************************************
A-1849-212-A KARAOKE BOARD, COMPLETE (RU)
************************
< CAPACITOR >
C202 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C203 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C204 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C206 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C207 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C209 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C210 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C211 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C213 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C214 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C215 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C216 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C217 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C218 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C219 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C220 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C221 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C222 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C224 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C226 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
< CONNECTOR >
CN201 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
< DIODE >
D202 6-500-848-01 DIODE MC2840-T112-1
< IC >
IC201 6-713-989-01 IC NJM2783V (TE2)
IC203 6-718-174-01 IC NJU72341V (TE2)
< JACK >
J201 1-819-878-51 JACK (MIC 1)
J202 1-819-878-51 JACK (MIC 2)
< RESISTOR >
R203 1-216-845-11 METAL CHIP 100K 5% 1/10W
R204 1-216-845-11 METAL CHIP 100K 5% 1/10W
R205 1-216-821-11 METAL CHIP 1K 5% 1/10W
R206 1-216-821-11 METAL CHIP 1K 5% 1/10W
R207 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R208 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R209 1-216-841-11 METAL CHIP 47K 5% 1/10W
R210 1-216-821-11 METAL CHIP 1K 5% 1/10W
R211 1-216-841-11 METAL CHIP 47K 5% 1/10W
R212 1-216-837-11 METAL CHIP 22K 5% 1/10W
R213 1-216-833-11 METAL CHIP 10K 5% 1/10W
R214 1-216-857-11 METAL CHIP 1M 5% 1/10W
AMP
KARAOKE
Ver. 1.1
