Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E190/E290/E490/E690
94
JR07 1-216-864-11 SHORT CHIP 0
JR08 1-216-864-11 SHORT CHIP 0
JR09 1-216-296-11 SHORT CHIP 0
JR10 1-216-295-91 SHORT CHIP 0
JR11 1-216-295-91 SHORT CHIP 0
JR12 1-216-864-11 SHORT CHIP 0
JR13 1-216-295-91 SHORT CHIP 0
JR15 1-216-295-91 SHORT CHIP 0
JR16 1-216-296-11 SHORT CHIP 0
JR17 1-216-296-11 SHORT CHIP 0
JR18 1-216-296-11 SHORT CHIP 0
JR19 1-216-296-11 SHORT CHIP 0
JR20 1-216-296-11 SHORT CHIP 0
JR22 1-216-296-11 SHORT CHIP 0
JR23 1-216-296-11 SHORT CHIP 0
JR24 1-216-296-11 SHORT CHIP 0
JR25 1-216-296-11 SHORT CHIP 0
JR26 1-216-296-11 SHORT CHIP 0
JR27 1-216-296-11 SHORT CHIP 0
JR28 1-216-296-11 SHORT CHIP 0
JR29 1-216-296-11 SHORT CHIP 0
JR30 1-216-296-11 SHORT CHIP 0
JR31 1-216-296-11 SHORT CHIP 0
JR33 1-216-296-11 SHORT CHIP 0
JR34 1-216-296-11 SHORT CHIP 0
JR35 1-216-296-11 SHORT CHIP 0
JR36 1-216-296-11 SHORT CHIP 0
JR37 1-216-296-11 SHORT CHIP 0
JR38 1-216-296-11 SHORT CHIP 0
JR39 1-216-296-11 SHORT CHIP 0
JR40 1-216-296-11 SHORT CHIP 0
JR41 1-216-296-11 SHORT CHIP 0
< COIL >
L01 1-481-781-21 INDUCTOR 47uH
< FLUORESCENT INDICATOR TUBE >
ND01 1-483-411-11 VACUUM FLUORESCENT DISPLAY
< TRANSISTOR >
Q03 6-552-713-01 TR QS5W2TR
< RESISTOR >
R04 1-216-821-11 METAL CHIP 1K 5% 1/10W
R06 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R13 1-216-833-11 METAL CHIP 10K 5% 1/10W
R14 1-216-805-11 METAL CHIP 47 5% 1/10W
R17 1-216-805-11 METAL CHIP 47 5% 1/10W
R22 1-216-845-11 METAL CHIP 100K 5% 1/10W
R29 1-216-813-11 METAL CHIP 220 5% 1/10W
R30 1-216-805-11 METAL CHIP 47 5% 1/10W
R31 1-216-813-11 METAL CHIP 220 5% 1/10W
R32 1-216-813-11 METAL CHIP 220 5% 1/10W
R40 1-216-809-11 METAL CHIP 100 5% 1/10W
R41 1-216-821-11 METAL CHIP 1K 5% 1/10W
R42 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R43 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R44 1-216-809-11 METAL CHIP 100 5% 1/10W
R45 1-216-821-11 METAL CHIP 1K 5% 1/10W
R46 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R47 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S40 1-771-410-21 SWITCH, TACTILE (Z)
S41 1-771-410-21 SWITCH, TACTILE (VOL –)
S42 1-771-410-21 SWITCH, TACTILE (VOL +)
S43 1-771-410-21 SWITCH, TACTILE (N)
S44 1-771-410-21 SWITCH, TACTILE (x)
S45 1-771-410-21 SWITCH, TACTILE (FUNCTION)
S46 1-771-410-21 SWITCH, TACTILE (.)
S47 1-771-410-21 SWITCH, TACTILE (>)
< TRANSFORMER >
T01 1-697-104-11 DC-DC CONVERTER TRANSFORMER
************************************************************
POWER KEY BOARD
****************
< CAPACITOR >
C303 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN301 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
< RESISTOR >
R301 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S301 1-771-410-21 SWITCH, TACTILE (\/1)
************************************************************
A-1846-432-A TUNER2 BOARD, COMPLETE (AEP, UK, SAF)
A-1846-434-A TUNER2 BOARD, COMPLETE (CND, PX)
A-1848-566-A TUNER2 BOARD, COMPLETE
(EXCEPT CND, AEP, UK, SAF, PX)
************
< CAPACITOR >
C101 1-100-155-91 CERAMIC CHIP 470PF 5% 100V
C102 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C103 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C105 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C107 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C108 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C109 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C110 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C111 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C112 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C113 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
< CONNECTOR >
CN101 1-779-544-21 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
CN102 1-780-923-11 TERMINAL (PAL)
(EXCEPT CND, AEP, UK, SAF, PX)
(ANTENNA 75Ω FM COAXIAL)
< DIODE >
D103 6-501-579-01 DIODE MC2837
Ver. 1.1
PANEL
POWER KEY TUNER2
