— 100 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
D212 8-719-987-63 DIODE 1N4148M
D213 8-719-987-63 DIODE 1N4148M
D301 8-719-109-93 DIODE RD6.2ESB2
D302 8-719-987-63 DIODE 1N4148M
D303 8-719-987-63 DIODE 1N4148M
D304 8-719-987-63 DIODE 1N4148M
D306 8-719-510-33 DIODE D2SBA20
D310 8-719-904-02 DIODE 1N4002T
D311 8-719-904-02 DIODE 1N4002T
D312 8-719-904-02 DIODE 1N4002T
D313 8-719-904-02 DIODE 1N4002T
D314 8-719-110-08 DIODE RD8.2ES-B2
D315 8-719-110-31 DIODE RD12ES-B2
D316 8-719-110-31 DIODE RD12ES-B2
D318 8-719-987-63 DIODE 1N4148M
D319 8-719-987-63 DIODE 1N4148M
D321 8-719-987-63 DIODE 1N4148M
D322 8-719-987-63 DIODE 1N4148M
D401 8-719-987-63 DIODE 1N4148M
< FUSE, FUSE HOLDER>
! F301 1-532-504-31 FUSE, TIME-LAG (T4AL/250V)
! F302 1-532-388-31 FUSE, TIME-LAG (T2AL/250V)
* F301H 1-533-213-31 HOLDER, FUSE
* F302H 1-533-213-31 HOLDER, FUSE
* F301HA 1-533-213-31 HOLDER, FUSE
* F302HA 1-533-213-31 HOLDER, FUSE
< IC >
IC201 8-759-242-58 IC TA8189N
IC301 8-749-920-14 IC STK-4412
IC303 8-759-473-59 IC LC75392
< JACK >
JK301 1-694-092-11 TERMINAL BOARD (SPEAKER)
JK302 1-779-715-11 JACK (LARGE TYPE) (PHONES)
< COIL >
L201 1-429-552-11 TRANSFORMER, BIAS OSCILLATION
L301 1-420-872-00 COIL, AIR-CORE
L302 1-420-872-00 COIL, AIR-CORE
< TRANSISTOR >
Q201 8-729-194-57 TRANSISTOR 2SC945-P
Q202 8-729-194-57 TRANSISTOR 2SC945-P
Q203 8-729-194-57 TRANSISTOR 2SC945-P
Q204 8-729-194-57 TRANSISTOR 2SC945-P
Q205 8-729-194-57 TRANSISTOR 2SC945-P
Q206 8-729-194-57 TRANSISTOR 2SC945-P
Q207 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q208 8-729-194-57 TRANSISTOR 2SC945-P
Q209 8-729-194-57 TRANSISTOR 2SC945-P
Q210 8-729-194-57 TRANSISTOR 2SC945-P
Q211 8-729-194-57 TRANSISTOR 2SC945-P
Q212 8-729-194-57 TRANSISTOR 2SC945-P
Q213 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q214 8-729-194-57 TRANSISTOR 2SC945-P
Q216 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q217 8-729-194-57 TRANSISTOR 2SC945-P
Q218 8-729-142-46 TRANSISTOR 2SC2001-LK
Q219 8-729-194-57 TRANSISTOR 2SC945-P
Q220 8-729-142-46 TRANSISTOR 2SC2001-LK
Q301 8-729-142-46 TRANSISTOR 2SC2001-LK
Q302 8-729-231-55 TRANSISTOR 2SC2878-AB
Q303 8-729-231-55 TRANSISTOR 2SC2878-AB
Q305 8-729-194-57 TRANSISTOR 2SC945-P
Q306 8-729-194-57 TRANSISTOR 2SC945-P
Q307 8-729-194-57 TRANSISTOR 2SC945-P
Q308 8-729-194-57 TRANSISTOR 2SC945-P
Q309 8-729-194-57 TRANSISTOR 2SC945-P
Q311 8-729-194-57 TRANSISTOR 2SC945-P
Q312 8-729-194-57 TRANSISTOR 2SC945-P
Q313 8-729-194-57 TRANSISTOR 2SC945-P
Q315 8-729-188-23 TRANSISTOR 2SD882-P
Q316 8-729-188-23 TRANSISTOR 2SD882-P
Q317 8-729-188-23 TRANSISTOR 2SD882-P
Q319 8-729-194-57 TRANSISTOR 2SC945-P
Q320 8-729-194-57 TRANSISTOR 2SC945-P
Q321 8-729-142-46 TRANSISTOR 2SC2001-LK
Q401 8-729-194-57 TRANSISTOR 2SC945-P
Q402 8-729-194-57 TRANSISTOR 2SC945-P
< RESISTOR >
R201 1-249-393-11 CARBON 10 5% 1/4W F
R202 1-249-393-11 CARBON 10 5% 1/4W F
R203 1-247-889-00 CARBON 270K 5% 1/4W
R204 1-247-889-00 CARBON 270K 5% 1/4W
R205 1-249-407-11 CARBON 150 5% 1/4W F
R205A 1-247-827-11 CARBON 680 5% 1/4W
R206 1-249-407-11 CARBON 150 5% 1/4W F
R206A 1-247-827-11 CARBON 680 5% 1/4W
R207 1-249-431-11 CARBON 15K 5% 1/4W
R208 1-249-431-11 CARBON 15K 5% 1/4W
R209 1-247-855-11 CARBON 10K 5% 1/4W
R210 1-247-863-11 CARBON 22K 5% 1/4W
R211 1-247-891-00 CARBON 330K 5% 1/4W
R212 1-247-891-00 CARBON 330K 5% 1/4W
R213 1-247-847-11 CARBON 4.7K 5% 1/4W
R214 1-247-847-11 CARBON 4.7K 5% 1/4W
R215 1-247-855-11 CARBON 10K 5% 1/4W
R216 1-249-431-11 CARBON 15K 5% 1/4W
R217 1-249-465-11 CARBON 47K 5% 1/4W
R218 1-247-704-11 CARBON 220 5% 1/4W F
R219 1-247-841-11 CARBON 2.7K 5% 1/4W
R220 1-249-434-11 CARBON 27K 5% 1/4W
R221 1-247-879-11 CARBON 100K 5% 1/4W
R222 1-247-879-11 CARBON 100K 5% 1/4W
R223 1-247-855-11 CARBON 10K 5% 1/4W
R224 1-247-855-11 CARBON 10K 5% 1/4W
R225 1-247-863-11 CARBON 22K 5% 1/4W
R226 1-247-863-11 CARBON 22K 5% 1/4W
R227 1-247-885-00 CARBON 180K 5% 1/4W
R228 1-247-885-00 CARBON 180K 5% 1/4W
R229 1-247-881-00 CARBON 120K 5% 1/4W
R230 1-247-881-00 CARBON 120K 5% 1/4W
R231 1-249-420-11 CARBON 1.8K 5% 1/4W F
MAIN
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
