Sony HCD-C20 - Page 50

— 102 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R386 1-260-094-11 CARBON 390 5% 1/2W
R387 1-260-094-11 CARBON 390 5% 1/2W
R388 1-249-431-11 CARBON 15K 5% 1/4W
! R389 1-208-601-11 WIREWOUND 0.1 10% 2W F
R391 1-249-434-11 CARBON 27K 5% 1/4W
R392 1-249-434-11 CARBON 27K 5% 1/4W
R393 1-249-430-11 CARBON 12K 5% 1/4W
R394 1-249-430-11 CARBON 12K 5% 1/4W
R395 1-249-420-11 CARBON 1.8K 5% 1/4W F
R396 1-247-716-11 CARBON 1.8K 5% 1/4W F
R397 1-249-434-11 CARBON 27K 5% 1/4W
R398 1-249-434-11 CARBON 27K 5% 1/4W
R399 1-247-867-11 CARBON 33K 5% 1/4W
R400 1-247-867-11 CARBON 33K 5% 1/4W
R401 1-249-427-11 CARBON 6.8K 5% 1/4W F
R402 1-249-427-11 CARBON 6.8K 5% 1/4W F
R403 1-249-430-11 CARBON 12K 5% 1/4W
R404 1-249-430-11 CARBON 12K 5% 1/4W
R430 1-247-867-11 CARBON 33K 5% 1/4W
R432 1-247-855-11 CARBON 10K 5% 1/4W
R433 1-247-871-11 CARBON 47K 5% 1/4W
R435 1-246-461-15 CARBON 330 5% 1/4W
R436 1-247-871-11 CARBON 47K 5% 1/4W
R437 1-247-871-11 CARBON 47K 5% 1/4W
R438 1-247-871-11 CARBON 47K 5% 1/4W
R439 1-247-871-11 CARBON 47K 5% 1/4W
R440 1-247-871-11 CARBON 47K 5% 1/4W
R441 1-247-871-11 CARBON 47K 5% 1/4W
R442 1-247-871-11 CARBON 47K 5% 1/4W
R443 1-247-871-11 CARBON 47K 5% 1/4W
R450 1-247-871-11 CARBON 47K 5% 1/4W
R451 1-247-871-11 CARBON 47K 5% 1/4W
R452 1-249-417-11 CARBON 1K 5% 1/4W F
< RELAY >
RY301 1-515-921-11 RELAY (12V)
< VARIABLE RESISTOR >
SFR201 1-228-994-00 RES, ADJ, METAL 10K
**************************************************************
* A-4403-184-A MAIN BOARD, COMPLETE (US,CND,MX)
********************
* A-4403-200-A MAIN BOARD, COMPLETE (E,SP,MY)
********************
* A-4403-328-A MAIN BOARD, COMPLETE (AUS)
********************
7-685-645-79 SCREW +BVTP 3X6 TYPE2 SLIT
< CAPACITOR >
C201 1-162-282-31 CERAMIC 100PF 10% 50V
C202 1-162-282-31 CERAMIC 100PF 10% 50V
C203 1-162-294-31 CERAMIC 0.001uF 10% 50V
C204 1-162-294-31 CERAMIC 0.001uF 10% 50V
C205 1-162-282-31 CERAMIC 100PF 10% 50V
C206 1-162-282-31 CERAMIC 100PF 10% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-130-485-00 MYLAR 0.015uF 5% 50V
C210 1-130-485-00 MYLAR 0.015uF 5% 50V
C211 1-126-044-11 ELECT 1uF 20% 50V
C212 1-126-044-11 ELECT 1uF 20% 50V
C215 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C216 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C217 1-162-282-31 CERAMIC 100PF 10% 50V
C218 1-162-282-31 CERAMIC 100PF 10% 50V
C219 1-126-962-11 ELECT 3.3uF 20% 50V
C220 1-126-962-11 ELECT 3.3uF 20% 50V
C221 1-126-644-11 ELECT 100uF 20% 16V
C222 1-126-644-11 ELECT 100uF 20% 16V
C223 1-162-294-31 CERAMIC 0.001uF 10% 50V
C224 1-162-294-31 CERAMIC 0.001uF 10% 50V
C225 1-126-962-11 ELECT 3.3uF 20% 50V
C226 1-126-962-11 ELECT 3.3uF 20% 50V
C228 1-126-964-11 ELECT 10uF 20% 50V
C230 1-137-350-11 FILM 0.015uF 5% 100V
C231 1-137-150-11 FILM 0.01uF 5% 100V
C232 1-130-479-00 MYLAR 0.0047uF 5% 50V
C233 1-130-487-00 MYLAR 0.022uF 5% 50V
C234 1-124-910-11 ELECT 47uF 20% 50V
C235 1-161-494-00 CERAMIC 0.022uF 25V
C237 1-126-025-11 ELECT 330uF 20% 16V
C238 1-126-962-11 ELECT 3.3uF 20% 50V
C239 1-162-292-31 CERAMIC 680PF 10% 50V
C240 1-162-292-31 CERAMIC 680PF 10% 50V
C241 1-126-644-11 ELECT 100uF 20% 16V
C242 1-126-959-11 ELECT 0.47uF 20% 50V
C243 1-124-767-00 ELECT 2.2uF 20% 50V
C281 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C282 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C401 1-162-288-31 CERAMIC 330PF 10% 50V
C402 1-162-288-31 CERAMIC 330PF 10% 50V
C403 1-126-959-11 ELECT 0.47uF 20% 50V
C404 1-126-959-11 ELECT 0.47uF 20% 50V
C405 1-126-959-11 ELECT 0.47uF 20% 50V
C406 1-126-959-11 ELECT 0.47uF 20% 50V
C407 1-126-959-11 ELECT 0.47uF 20% 50V
C408 1-126-959-11 ELECT 0.47uF 20% 50V
C409 1-126-959-11 ELECT 0.47uF 20% 50V
C410 1-126-959-11 ELECT 0.47uF 20% 50V
C411 1-162-199-31 CERAMIC 10PF 5% 50V
C412 1-162-199-31 CERAMIC 10PF 5% 50V
C415 1-162-290-31 CERAMIC 470PF 10% 50V
C416 1-162-290-31 CERAMIC 470PF 10% 50V
C417 1-130-485-00 MYLAR 0.015uF 5% 50V
C418 1-130-485-00 MYLAR 0.015uF 5% 50V
C419 1-162-292-31 CERAMIC 680PF 10% 50V
C420 1-162-292-31 CERAMIC 680PF 10% 50V
C421 1-162-294-31 CERAMIC 0.001uF 10% 50V
C422 1-162-294-31 CERAMIC 0.001uF 10% 50V
C425 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C426 1-162-301-11 CERAMIC 0.0015uF 30% 16V
MAIN
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
