— 104 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< DIODE >
D201 8-719-987-63 DIODE 1N4148M
D202 8-719-987-63 DIODE 1N4148M
D203 8-719-987-63 DIODE 1N4148M
D205 8-719-987-63 DIODE 1N4148M
D208 8-719-987-63 DIODE 1N4148M
D209 8-719-987-63 DIODE 1N4148M
D211 8-719-987-63 DIODE 1N4148M
D212 8-719-987-63 DIODE 1N4148M
D213 8-719-987-63 DIODE 1N4148M
D501 8-719-987-63 DIODE 1N4148M
D551 8-719-987-63 DIODE 1N4148M
D552 8-719-987-63 DIODE 1N4148M
D553 8-719-987-63 DIODE 1N4148M
D581 8-719-987-63 DIODE 1N4148M
D582 8-719-987-63 DIODE 1N4148M
D583 8-719-987-63 DIODE 1N4148M
D584 8-719-987-63 DIODE 1N4148M
D585 8-719-987-63 DIODE 1N4148M
D701 8-719-510-33 DIODE D2SBA20
D705 8-719-200-02 DIODE 10E2
D706 8-719-200-02 DIODE 10E2
D707 8-719-200-02 DIODE 10E2
D708 8-719-200-02 DIODE 10E2
D709 8-719-200-02 DIODE 10E2
D711 8-719-110-31 DIODE RD12ES-B2
D712 8-719-110-08 DIODE RD8.2ES-B2
D713 8-719-109-93 DIODE RD6.2ESB2
D714 8-719-110-31 DIODE RD12ES-B2
D741 8-719-110-31 DIODE RD12ES-B2
D781 8-719-987-63 DIODE 1N4148M
< FUSE, FUSE HOLDER>
! F701 1-576-104-11 FUSE (2A/250V) (US,CND,MX)
! F701 1-532-388-31 FUSE, TIME-LAG (T2AL/250V) (E,SP,MY,AUS)
* F701H 1-533-213-31 HOLDER, FUSE
* F701HA 1-533-213-31 HOLDER, FUSE
< IC >
IC201 8-759-242-58 IC TA8189N
IC401 8-759-473-59 IC LC75392
IC403 8-759-505-55 IC NJM4558L
IC501 8-749-013-85 IC STK405-070A
IC502 8-759-111-68 IC UPC1237HA
< JACK >
JK501 1-694-092-11 TERMINAL BOARD (SPEAKER)
JK502 1-779-715-11 JACK (LARGE TYPE)(PHONES)
< COIL >
L201 1-429-552-11 TRANSFORMER, BIAS OSCILLATION
* L501 1-420-872-00 COIL, AIR CORE
* L502 1-420-872-00 COIL, AIR CORE
< TRANSISTOR >
Q1 8-729-194-57 TRANSISTOR 2SC945-P
Q2 8-729-194-57 TRANSISTOR 2SC945-P
Q201 8-729-194-57 TRANSISTOR 2SC945-P
Q202 8-729-194-57 TRANSISTOR 2SC945-P
Q203 8-729-194-57 TRANSISTOR 2SC945-P
Q204 8-729-194-57 TRANSISTOR 2SC945-P
Q205 8-729-194-57 TRANSISTOR 2SC945-P
Q206 8-729-194-57 TRANSISTOR 2SC945-P
Q207 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q208 8-729-194-57 TRANSISTOR 2SC945-P
Q209 8-729-194-57 TRANSISTOR 2SC945-P
Q210 8-729-194-57 TRANSISTOR 2SC945-P
Q211 8-729-194-57 TRANSISTOR 2SC945-P
Q212 8-729-194-57 TRANSISTOR 2SC945-P
Q213 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q214 8-729-194-57 TRANSISTOR 2SC945-P
Q216 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q217 8-729-194-57 TRANSISTOR 2SC945-P
Q218 8-729-142-46 TRANSISTOR 2SC2001-LK
Q219 8-729-194-57 TRANSISTOR 2SC945-P
Q220 8-729-142-46 TRANSISTOR 2SC2001-LK
Q451 8-729-194-57 TRANSISTOR 2SC945-P
Q452 8-729-194-57 TRANSISTOR 2SC945-P
Q461 8-729-194-57 TRANSISTOR 2SC945-P
Q462 8-729-194-57 TRANSISTOR 2SC945-P
Q463 8-729-194-57 TRANSISTOR 2SC945-P
Q491 8-729-194-57 TRANSISTOR 2SC945-P
Q492 8-729-194-57 TRANSISTOR 2SC945-P
Q501 8-729-194-57 TRANSISTOR 2SC945-P
Q502 8-729-194-57 TRANSISTOR 2SC945-P
Q503 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q551 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q552 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q553 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q581 8-729-231-55 TRANSISTOR 2SC2878-AB
Q582 8-729-231-55 TRANSISTOR 2SC2878-AB
Q583 8-729-029-67 TRANSISTOR DTC114ESA-TP
Q584 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q585 8-729-029-86 TRANSISTOR DTC124ESA
Q586 8-729-029-86 TRANSISTOR DTC124ESA
Q587 8-729-231-55 TRANSISTOR 2SC2878-AB
Q588 8-729-231-55 TRANSISTOR 2SC2878-AB
Q589 8-729-029-56 TRANSISTOR DTA144ESA
Q701 8-729-188-23 TRANSISTOR 2SD882-P
Q702 8-729-142-46 TRANSISTOR 2SC2001-LK
Q703 8-729-188-23 TRANSISTOR 2SD882-P
Q704 8-729-142-46 TRANSISTOR 2SC2001-LK
Q705 8-729-188-23 TRANSISTOR 2SD882-P
Q706 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q707 8-729-194-57 TRANSISTOR 2SC945-P
Q751 8-729-194-57 TRANSISTOR 2SC945-P
Q781 8-729-029-86 TRANSISTOR DTC124ESA
Q782 8-729-029-86 TRANSISTOR DTC124ESA
< RESISTOR >
R1 1-247-855-11 CARBON 10K 5% 1/4W
R2 1-247-855-11 CARBON 10K 5% 1/4W
R201 1-249-393-11 CARBON 10 5% 1/4W F
R202 1-249-393-11 CARBON 10 5% 1/4W F
R203 1-247-889-00 CARBON 270K 5% 1/4W
MAIN
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
