Sony HCD-DX155 - MAIN MOTOR POWER; < NETWORK RESISTOR >; MOTOR BOARD; < SWITCH >

86
HCD-DX155/DX255
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R3324 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3325 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3326 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3327 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3401 1-216-809-11 METAL CHIP 100 5% 1/10W
R3402 1-216-809-11 METAL CHIP 100 5% 1/10W
R3403 1-216-797-11 METAL CHIP 10 5% 1/10W
R3404 1-216-864-11 SHORT CHIP 0
R3407 1-216-835-11 METAL CHIP 15K 5% 1/10W
R3415 1-216-797-11 METAL CHIP 10 5% 1/10W
R3416 1-216-797-11 METAL CHIP 10 5% 1/10W
R3419 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3420 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3421 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3422 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3423 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3424 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3425 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3426 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3427 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3501 1-216-809-11 METAL CHIP 100 5% 1/10W
(DX255)
R3502 1-216-809-11 METAL CHIP 100 5% 1/10W
(DX255)
R3503 1-216-797-11 METAL CHIP 10 5% 1/10W
(DX255)
R3504 1-216-864-11 SHORT CHIP 0 (DX255)
R3507 1-216-835-11 METAL CHIP 15K 5% 1/10W
(DX255)
R3515 1-216-797-11 METAL CHIP 10 5% 1/10W
(DX255)
R3516 1-216-797-11 METAL CHIP 10 5% 1/10W
(DX255)
R3519 1-216-136-00 RES-CHIP 2.7 5% 1/8W
(DX255)
R3520 1-216-136-00 RES-CHIP 2.7 5% 1/8W
(DX255)
R3551 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3553 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3554 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3555 1-216-864-11 SHORT CHIP 0
R4002 1-216-864-11 SHORT CHIP 0
< NETWORK RESISTOR >
RB501 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB601 1-236-908-11 RES, CHIP NETWORK 10K (3216)
RB602 1-236-908-11 RES, CHIP NETWORK 10K (3216)
RB603 1-236-908-11 RES, CHIP NETWORK 10K (3216)
RB604 1-236-908-11 RES, CHIP NETWORK 10K (3216)
RB605 1-233-411-11 RES, CHIP NETWORK 220 (3216)
RB606 1-233-411-11 RES, CHIP NETWORK 220 (3216)
RB607 1-233-411-11 RES, CHIP NETWORK 220 (3216)
RB608 1-233-411-11 RES, CHIP NETWORK 220 (3216)
RB609 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB610 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1103 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1104 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1105 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1106 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1107 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1108 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1111 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1112 1-234-371-21 RES, NETWORK 47 (1005X4)
RB1113 1-234-371-21 RES, NETWORK 47 (1005X4)
RB1114 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1115 1-234-372-11 RES, NETWORK 100 (1005X4)
< VIBRATOR >
X502 1-795-058-21 VIBRATOR, CERAMIC 5MHz
X1102 1-813-539-11 QUARTZ CRYSTAL UNIT 27MHz
X3051 1-795-660-21 QUARTZ CRYSTAL UNIT 49.152MHz
*************************************************************
MOTOR BOARD
*************
< SWITCH >
S761 1-786-704-11 SWITCH, LEVER (SUB TRY OUT)
*************************************************************
A-1144-950-A POWER BOARD, COMPLETE
(DX155: E3, SP, AUS)
A-1146-005-A POWER BOARD, COMPLETE
(DX155: US, CND/DX255)
A-1146-091-A POWER BOARD, COMPLETE (DX155: MX)
***********************
< CAPACITOR >
0 C901 1-165-529-11 MYLAR 0.22uF 10 275V
0 C902 1-165-529-11 MYLAR 0.22uF 10 275V
0 C903 1-112-330-11 ELECT (BLOCK) 1000uF 20% 200V
(DX155: US, CND/DX255)
0 C903 1-112-331-11 ELECT (BLOCK) 1000uF 20% 250V
(DX155: MX)
0 C903 1-112-333-11 ELECT (BLOCK) 330uF 20% 450V
(DX155: E3, SP, AUS)
0 C905 1-112-334-91 FILM 0.01uF 5% 400V
(DX155: US, CND, MX/DX255)
0 C905 1-112-335-91 FILM 0.0033uF 5% 400V
(DX155: E3, SP, AUS)
0 C906 1-117-815-31 FILM 1000PF 3% 1.5KV
(DX155: E3, SP, AUS)
0 C906 1-117-828-31 FILM 3300PF 3% 1.5KV
(DX155: US, CND, MX/DX255)
0 C907 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(DX155: E3, SP, AUS)
0 C907 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
(DX155: US, CND, MX/DX255)
0 C908 1-107-909-11 ELECT 47uF 20% 35V
0 C909 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
0 C910 1-107-906-11 ELECT 10uF 20% 50V
(DX155: US, CND, MX/DX255)
0 C910 1-107-907-11 ELECT 22uF 20% 50V
(DX155: E3, SP, AUS)
0 C911 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
0 C913 1-117-693-11 CERAMIC 100PF 10% 250V
0 C918 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C920 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C922 1-128-560-11 ELECT 22uF 20% 100V
MAIN MOTOR POWER
Ver. 1.2
