Sony HCD-DX155 - POWER; < DIODE >; < GROUND TERMINAL BOARD >; < FUSE HOLDER >

87
HCD-DX155/DX255
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
0 C923 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
0 C924 1-126-961-11 ELECT 2.2uF 20% 50V
0 C925 1-107-974-81 CERAMIC 47PF 5% 2KV
0 C928 1-113-896-11 CERAMIC 220PF 10% 250V
(DX155: US, CND, MX/DX255)
0 C928 1-113-900-11 CERAMIC 470PF 10% 250V
(DX155: E3, SP, AUS)
0 C929 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
0 C930 1-117-693-11 CERAMIC 100PF 10% 250V
C931 1-117-580-91 FILM 47000PF 5% 630V
(DX155: MX)
C932 1-100-924-21 ELECT 2200uF 20% 35V
C933 1-100-924-21 ELECT 2200uF 20% 35V
C934 1-112-831-11 ELECT 2200uF 20% 35V
C935 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C936 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C937 1-100-756-91 CERAMIC CHIP 0.047uF 50V
0 C938 1-113-898-11 CERAMIC 330PF 10% 250V
(DX155: US, CND, MX/DX255)
0 C938 1-117-698-51 CERAMIC 680PF 10% 250V
(DX155: E3, SP, AUS)
C939 1-136-165-00 FILM 0.1uF 5% 50V
C940 1-128-947-31 ELECT 3300uF 20% 10V
C941 1-128-954-11 ELECT 1000uF 20% 25V
C942 1-126-941-11 ELECT 470uF 20% 25V
C943 1-126-933-11 ELECT 100uF 20% 16V
C944 1-128-951-21 ELECT 2200uF 20% 16V
C945 1-126-935-11 ELECT 470uF 20% 16V
C946 1-128-950-21 ELECT 1000uF 20% 16V
C947 1-104-658-91 ELECT 100uF 20% 10V
C948 1-126-925-91 ELECT 470uF 20% 10V
C949 1-165-722-11 ELECT 100uF 20% 10V
C951 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C952 1-100-756-91 CERAMIC CHIP 0.047uF 50V
C953 1-117-214-11 CERAMIC 0.001uF 10% 2KV
C954 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C955 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C958 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C960 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
0 C963 1-117-699-11 CERAMIC 0.001uF 99% 250V
(DX155: E3, SP, AUS)
0 C963 1-113-907-51 CERAMIC 0.0022uF 99% 250V
(DX155: US, CND, MX/DX255)
0 C964 1-117-699-11 CERAMIC 0.001uF 99% 250V
(DX155: E3, SP, AUS)
0 C964 1-113-907-51 CERAMIC 0.0022uF 99% 250V
(DX155: US, CND, MX/DX255)
0 C965 1-117-699-11 CERAMIC 0.001uF 99% 250V
(DX155: E3, SP, AUS)
C967 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C968 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C969 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C970 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C971 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C976 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
0 D901 8-719-082-57 DIODE D5SBA60F01
0 D905 8-719-063-74 DIODE D1NL20U-TR2
0 D906 6-501-193-01 DIODE 1SS355WTE-17
0 D907 6-501-193-01 DIODE 1SS355WTE-17
0 D908 6-501-193-01 DIODE 1SS355WTE-17
0 D909 6-501-193-01 DIODE 1SS355WTE-17
0 D910 6-501-193-01 DIODE 1SS355WTE-17
0 D913 6-500-241-01 DIODE SARS03
0 D914 6-501-193-01 DIODE 1SS355WTE-17
0 D915 8-719-977-28 DIODE UDZSTE-1710B
0 D921 6-501-424-01 DIODE STO2D-140
0 D922 8-719-063-74 DIODE D1NL20U-TR2
0 D923 8-719-977-28 DIODE UDZSTE-1710B
0 D924 8-719-083-69 DIODE UDZSTE-1724B
0 D925 8-719-069-54 DIODE UDZSTE-175.1B
0 D926 8-719-977-28 DIODE UDZSTE-1710B
D931 6-501-413-01 DIODE FCU20UC20
D932 8-719-069-54 DIODE UDZSTE-175.1B
D941 6-500-288-11 DIODE EK19LF-F7
D942 8-719-080-53 DIODE RK36LF-B3
D943 8-719-080-53 DIODE RK36LF-B3
D944 6-500-288-11 DIODE EK19LF-F7
D945 8-719-083-67 DIODE UDZSTE-1720B
< GROUND TERMINAL BOARD >
EB901 1-537-770-21 TERMINAL BOARD, GROUND
EB902 1-537-770-21 TERMINAL BOARD, GROUND
EB903 1-537-770-21 TERMINAL BOARD, GROUND
EB904 1-537-770-21 TERMINAL BOARD, GROUND
< FUSE HOLDER >
FH901 1-533-313-11 FUSE HOLDER 0A 0V
FH902 1-533-313-11 FUSE HOLDER 0A 0V
< FUSIBLE >
0 FR901 1-220-886-11 FUSIBLE 0.1 10% 1W
0 FR902 1-220-886-11 FUSIBLE 0.1 10% 1W
(DX155: US, CND, MX/DX255)
< IC >
0 IC901 6-707-741-01 IC STR-F6138-LF1352
(DX155: US, CND, MX/DX255)
0 IC901 6-707-742-01 IC STR-F6168-LF1352 (DX155: E3, SP, AUS)
0 IC921 6-707-740-01 IC STR-V153
IC931 8-759-648-34 IC TA76431AS (TPE6)
IC941 6-707-746-01 IC SI-3120KM-TL
IC942 6-707-745-10 IC SI-3050KM-TL
IC943 6-707-744-01 IC SI-3033KM-TL
IC951 6-707-743-01 IC TA76L431S (TPE6, Q)
< COIL >
L931 1-457-226-11 INDUCTOR 10uH
L941 1-414-398-11 INDUCTOR 10uH
L942 1-414-398-11 INDUCTOR 10uH
L945 1-414-398-11 INDUCTOR 10uH
L947 1-414-398-11 INDUCTOR 10uH
POWER
