Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC68/EC78
52
< JUMPER RESISTOR >
JR501 1-216-864-11 SHORT CHIP 0
JR502 1-216-864-11 SHORT CHIP 0
JR503 1-216-864-11 SHORT CHIP 0
< TRANSFORMER >
L501 1-456-094-11 TRANSFORMER, BIAS OSCILLATION
< TRANSISTOR >
Q501 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q502 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R501 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R502 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R503 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R504 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R505 1-216-835-11 METAL CHIP 15K 5% 1/10W
R506 1-216-835-11 METAL CHIP 15K 5% 1/10W
R507 1-216-851-11 METAL CHIP 330K 5% 1/10W
R508 1-216-851-11 METAL CHIP 330K 5% 1/10W
R509 1-216-811-11 METAL CHIP 150 5% 1/10W
R510 1-216-811-11 METAL CHIP 150 5% 1/10W
R511 1-216-845-11 METAL CHIP 100K 5% 1/10W
R512 1-216-845-11 METAL CHIP 100K 5% 1/10W
R513 1-216-845-11 METAL CHIP 100K 5% 1/10W
R514 1-216-845-11 METAL CHIP 100K 5% 1/10W
R515 1-216-864-11 SHORT CHIP 0
R516 1-216-864-11 SHORT CHIP 0
R517 1-216-821-11 METAL CHIP 1K 5% 1/10W
R518 1-216-821-11 METAL CHIP 1K 5% 1/10W
R519 1-216-841-11 METAL CHIP 47K 5% 1/10W
R520 1-216-841-11 METAL CHIP 47K 5% 1/10W
R521 1-216-841-11 METAL CHIP 47K 5% 1/10W
R522 1-216-841-11 METAL CHIP 47K 5% 1/10W
R523 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R524 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R525 1-216-851-11 METAL CHIP 330K 5% 1/10W
R526 1-216-851-11 METAL CHIP 330K 5% 1/10W
R527 1-216-851-11 METAL CHIP 330K 5% 1/10W
R528 1-216-851-11 METAL CHIP 330K 5% 1/10W
R529 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R530 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R531 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R532 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R533 1-216-837-11 METAL CHIP 22K 5% 1/10W
R534 1-216-835-11 METAL CHIP 15K 5% 1/10W
R535 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R536 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R537 1-216-833-11 METAL CHIP 10K 5% 1/10W
R538 1-216-833-11 METAL CHIP 10K 5% 1/10W
R539 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R540 1-216-805-11 METAL CHIP 47 5% 1/10W
R541 1-216-805-11 METAL CHIP 47 5% 1/10W
R543 1-216-809-11 METAL CHIP 100 5% 1/10W
R544 1-216-809-11 METAL CHIP 100 5% 1/10W
R545 1-216-817-11 METAL CHIP 470 5% 1/10W
R546 1-216-817-11 METAL CHIP 470 5% 1/10W
< SWITCH >
S501 1-762-369-11 SWITCH, SLIDE (REC/PB)
************************************************************
HI AMP BOARD (EC78)
************
< CAPACITOR >
C151 1-126-960-11 ELECT 1uF 20% 50V
C152 1-126-960-11 ELECT 1uF 20% 50V
C153 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C154 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C155 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C156 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C157 1-126-960-11 ELECT 1uF 20% 50V
C158 1-126-960-11 ELECT 1uF 20% 50V
C159 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C160 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C161 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C162 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C166 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C169 1-126-968-11 ELECT 100uF 20% 50V
(EC78: E2, E3, E51, MX, AR)
C169 1-128-576-11 ELECT 100uF 20% 63V
(EC78: AEP, RU)
C170 1-126-968-11 ELECT 100uF 20% 50V
(EC78: E2, E3, E51, MX, AR)
C170 1-128-576-11 ELECT 100uF 20% 63V
(EC78: AEP, RU)
C173 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C174 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C175 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C176 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C178 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN151 1-819-134-11 PIN, CONNECTOR 6P
CN152 1-784-766-11 CONNECTOR, FFC 5P
< DIODE >
D151 6-500-335-01 DIODE MC2838-T112-1
D152 6-501-817-01 DIODE MA2J1110GLS0
< IC >
IC151 6-705-621-01 IC STK433-070
< JUMPER RESISTOR >
JR151 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q151 6-551-270-01 TRANSISTOR 2SA2026
Q152 6-551-270-01 TRANSISTOR 2SA2026
< RESISTOR >
R151 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R152 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R153 1-216-837-11 METAL CHIP 22K 5% 1/10W
R154 1-216-837-11 METAL CHIP 22K 5% 1/10W
R155 1-216-841-11 METAL CHIP 47K 5% 1/10W
