Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC68/EC78
60
R368 1-216-833-11 METAL CHIP 10K 5% 1/10W
R369 1-216-821-11 METAL CHIP 1K 5% 1/10W
R370 1-216-821-11 METAL CHIP 1K 5% 1/10W
R371 1-216-821-11 METAL CHIP 1K 5% 1/10W
R372 1-216-821-11 METAL CHIP 1K 5% 1/10W
R373 1-216-864-11 SHORT CHIP 0
R374 1-216-821-11 METAL CHIP 1K 5% 1/10W
R375 1-216-864-11 SHORT CHIP 0
R376 1-216-833-11 METAL CHIP 10K 5% 1/10W
R377 1-216-833-11 METAL CHIP 10K 5% 1/10W
R378 1-216-839-11 METAL CHIP 33K 5% 1/10W
R379 1-216-843-11 METAL CHIP 68K 5% 1/10W
R380 1-216-817-11 METAL CHIP 470 5% 1/10W
R381 1-216-833-11 METAL CHIP 10K 5% 1/10W
R382 1-216-833-11 METAL CHIP 10K 5% 1/10W
R383 1-216-833-11 METAL CHIP 10K 5% 1/10W
R384 1-216-833-11 METAL CHIP 10K 5% 1/10W
R385 1-216-821-11 METAL CHIP 1K 5% 1/10W
R386 1-216-821-11 METAL CHIP 1K 5% 1/10W
R387 1-216-821-11 METAL CHIP 1K 5% 1/10W
R389 1-216-838-11 METAL CHIP 27K 5% 1/10W
(EC68: UK)
R389 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EC68: AEP, RU, E2, E3, E51, MX, AR, AUS)
R389 1-216-845-11 METAL CHIP 100K 5% 1/10W
(EC78)
R390 1-216-833-11 METAL CHIP 10K 5% 1/10W
R391 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EC68: AEP, UK, RU/EC78: AEP, RU)
R391 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EC68: AUS)
R391 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
(EC68: E3/EC78: E3)
R391 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EC68: E2/EC78: E2)
R391 1-216-845-11 METAL CHIP 100K 5% 1/10W
(EC68: E51, MX, AR/EC78: E51, MX, AR)
R392 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EC68: RU, E2, E3, E51, MX, AR, AUS/
EC78: RU, E2, E3, E51, MX, AR)
R396 1-216-851-11 METAL CHIP 330K 5% 1/10W
R400 1-216-821-11 METAL CHIP 1K 5% 1/10W
R401 1-216-821-11 METAL CHIP 1K 5% 1/10W
R402 1-216-845-11 METAL CHIP 100K 5% 1/10W
R405 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R406 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R412 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R413 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R414 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R415 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R416 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R417 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R418 1-216-835-11 METAL CHIP 15K 5% 1/10W
R419 1-216-838-11 METAL CHIP 27K 5% 1/10W
R420 1-216-845-11 METAL CHIP 100K 5% 1/10W
R421 1-216-833-11 METAL CHIP 10K 5% 1/10W
R422 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R425 1-216-864-11 SHORT CHIP 0 (EC68: UK)
R426 1-216-845-11 METAL CHIP 100K 5% 1/10W
R428 1-216-841-11 METAL CHIP 47K 5% 1/10W
R446 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R447 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< ROTARY ENCODER >
S301 1-786-417-11 ENCODER, ROTARY (VOLUME)
< SWITCH >
SW303 1-771-410-21 SWITCH, TACTILE (l m − TUNING)
SW304 1-771-410-21 SWITCH, TACTILE (FUNCTION)
SW305 1-771-410-21 SWITCH, TACTILE (TUNING + M L)
SW311 1-771-410-21 SWITCH, TACTILE (CD N)
SW312 1-771-410-21 SWITCH, TACTILE (X)
SW313 1-771-410-21 SWITCH, TACTILE (x)
SW314 1-771-410-21 SWITCH, TACTILE (FOLDER +)
SW315 1-771-410-21 SWITCH, TACTILE (FOLDER −)
SW316 1-771-410-21 SWITCH, TACTILE (EQ)
SW317 1-771-410-21 SWITCH, TACTILE (DSGX)
SW318 1-771-410-21 SWITCH, TACTILE (PLAY MODE/TUNING MODE)
SW319 1-771-410-21 SWITCH, TACTILE (DISPLAY)
< VIBRATOR >
X301 1-814-067-11 OSCILLATOR, CRYSTAL (32.768kHz)
X302 1-813-548-21 VIBRATOR, CERAMIC (6MHz)
************************************************************
PT BOARD
*********
< CAPACITOR >
C051 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C052 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN051 1-819-972-11 HOLDER, CABLE 8P
0 CN053 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
D051 6-500-334-01 DIODE MC2836-T112-1
D052 6-500-335-01 DIODE MC2838-T112-1
D055 6-500-335-01 DIODE MC2838-T112-1
< TRANSFORMER >
0 PT001 1-443-912-11 TRANSFORMER, POWER
(EC68: AEP, UK, RU/EC78: AEP, RU)
0 PT002 1-445-105-11 TRANSFORMER, POWER (EC68: E2, E3, E51,
MX, AR, AUS/EC78: E2, E3, E51, MX, AR)
< RELAY >
0 RY001 1-755-334-11 RELAY, AC POWER
(EC68: AEP, UK, RU/EC78: AEP, RU)
0 RY002 1-755-496-11 RELAY (EC68: E2, E3, E51, MX, AR, AUS/
EC78: E2, E3, E51, MX, AR)
< SWITCH >
0 S001 1-786-408-11 SELECTOR, VOLTAGE (SWS-2301)
(VOLTAGE SELECTOR)
(EC68: E2, E3, E51/EC78: E2, E3, E51)
************************************************************
PANEL PT
