Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
32
HCD-EP30/EP40
DISPLAY HEADPHONE MAIN
R629 1-249-417-11 CARBON 1K 5% 1/4W
R631 1-249-437-11 CARBON 47K 5% 1/4W
R632 1-249-437-11 CARBON 47K 5% 1/4W
R633 1-249-437-11 CARBON 47K 5% 1/4W
R634 1-249-437-11 CARBON 47K 5% 1/4W
R636 1-249-437-11 CARBON 47K 5% 1/4W
R638 1-249-437-11 CARBON 47K 5% 1/4W
R639 1-249-417-11 CARBON 1K 5% 1/4W
R640 1-249-417-11 CARBON 1K 5% 1/4W
R641 1-249-437-11 CARBON 47K 5% 1/4W
R642 1-249-433-11 CARBON 22K 5% 1/4W
R643 1-249-433-11 CARBON 22K 5% 1/4W
R644 1-249-433-11 CARBON 22K 5% 1/4W
R645 1-249-437-11 CARBON 47K 5% 1/4W
R646 1-249-437-11 CARBON 47K 5% 1/4W
R647 1-249-437-11 CARBON 47K 5% 1/4W
R657 1-249-409-11 CARBON 220 5% 1/4W
R658 1-249-437-11 CARBON 47K 5% 1/4W
R663 1-249-429-11 CARBON 10K 5% 1/4W
R664 1-249-429-11 CARBON 10K 5% 1/4W
R665 1-249-429-11 CARBON 10K 5% 1/4W
R666 1-249-429-11 CARBON 10K 5% 1/4W
(US, CND, E, AUS)
R667 1-247-847-11 CARBON 47K 5% 1/4W
R668 1-249-421-11 CARBON 2.2K 5% 1/4W
(US, CND)
< IC >
REM601 8-749-016-29 IC RPM6938 (REMOTE CONTROL RECEIVER)
< SWITCH >
SW601 1-570-472-11 SWITCH, KEY BOARD (I/1)
SW602 1-570-472-11 SWITCH, KEY BOARD (REPEAT)
SW603 1-570-472-11 SWITCH, KEY BOARD (SHUFFLE)
SW604 1-570-472-11 SWITCH, KEY BOARD
(TUNER MEM, ENTER PGM)
SW605 1-570-472-11 SWITCH, KEY BOARD (PRESET –)
SW606 1-570-472-11 SWITCH, KEY BOARD (PRESET +)
SW607 1-570-472-11 SWITCH, KEY BOARD (TUNING +, M >)
SW608 1-570-472-11 SWITCH, KEY BOARD
(TUNER DSPL (EP40), x)
SW609 1-570-472-11 SWITCH, KEY BOARD (TUNING –, . m )
SW610 1-570-472-11 SWITCH, KEY BOARD (RDS (EP40), u)
SW611 1-570-472-11 SWITCH, KEY BOARD (REMAIN, CD)
SW612 1-570-472-11 SWITCH, KEY BOARD (TAPE)
SW613 1-570-472-11 SWITCH, KEY BOARD (TUNER)
SW614 1-570-472-11 SWITCH, KEY BOARD (MUSIC MENU)
SW615 1-570-472-11 SWITCH, KEY BOARD (MEGA BASS)
SW621 1-554-088-00 SWITCH, KEY BOARD (VOLUME –)
SW622 1-554-088-00 SWITCH, KEY BOARD (VOLUME +)
SW631 1-786-224-11 SW, SLIDE (MONO STEREO, ISS)
< VIBRATOR >
X602 1-795-398-11 VIBRATOR, CRYSTAL (6MHz)
**************************************************************
A-4726-714-A HEADPHONE BOARD, COMPLETE
***************************
< JACK >
JK401 1-815-813-11 JACK (LARGE TYPE) (PHONES)
< RESISTOR >
R412 1-249-408-11 CARBON 180 5% 1/4W
R413 1-249-408-11 CARBON 180 5% 1/4W
**************************************************************
A-4726-713-A MAIN BOARD, COMPLETE (EP40)
A-4726-786-A MAIN BOARD, COMPLETE (EP30: AEP, UK)
A-4726-868-A MAIN BOARD, COMPLETE
(US, CND, SP, EA, TW, MX, AR, AUS)
*********************
1-424-881-11 AM BAR ANT
4-235-969-01 BAR HOLDER
7-682-549-09 SCREW +B 3X10
< TERMINAL >
ANT101 1-694-848-11 TERMINAL BOARD (ANT FM) (FM ANT)
< CAPACITOR >
C102 1-162-282-31 CERAMIC 100PF 10% 50V
C104 1-162-294-31 CERAMIC 0.001uF 10% 50V
C105 1-162-294-31 CERAMIC 0.001uF 10% 50V
C107 1-130-471-00 FILM 0.001uF 5% 50V
C108 1-126-963-11 ELECT 4.7uF 20% 50V
C109 1-102-936-00 CERAMIC 3.0PF 0.25PF 50V
C110 1-162-205-31 CERAMIC 18PF 5% 50V
C111 1-162-294-31 CERAMIC 0.001uF 10% 50V
C112 1-162-294-31 CERAMIC 0.001uF 10% 50V
C113 1-130-485-00 FILM 0.015uF 5% 50V
C114 1-130-485-00 FILM 0.015uF 5% 50V
C116 1-161-494-00 CERAMIC 0.022uF 25V
C117 1-130-477-00 FILM 0.0033uF 5% 50V
C118 1-130-477-00 FILM 0.0033uF 5% 50V
C119 1-126-960-11 ELECT 1uF 20% 50V
C120 1-126-960-11 ELECT 1uF 20% 50V
C121 1-162-290-31 CERAMIC 470PF 10% 50V
C122 1-126-957-11 ELECT 0.22uF 20% 50V
C123 1-126-959-11 ELECT 0.47uF 20% 50V
C124 1-126-960-11 ELECT 1uF 20% 50V
C126 1-162-306-11 CERAMIC 0.01uF 30% 16V
C127 1-127-884-11 CERAMIC 0.047uF 10% 50V
C128 1-126-935-11 ELECT 470uF 20% 16V
C129 1-126-963-11 ELECT 4.7uF 20% 50V
C130 1-126-964-11 ELECT 10uF 20% 50V
C131 1-127-884-11 CERAMIC 0.047uF 10% 50V
C135 1-110-342-11 FILM 390PF 5% 50V
C136 1-102-947-00 FILM 10PF 0.5PF 50V
C140 1-127-884-11 CERAMIC 0.047uF 10% 50V
C142 1-127-888-11 CERAMIC 0.1uF 10% 50V
(EP40)
C143 1-126-934-11 ELECT 220uF 20% 16V
(EP40)
C144 1-161-494-00 CERAMIC 0.022uF 25V
