Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
36
HCD-EP30/EP40
< CAPACITOR >
C402 1-101-005-00 CERAMIC 22000PF 50V
C404 1-101-005-00 CERAMIC 22000PF 50V
C406 1-101-005-00 CERAMIC 22000PF 50V
C408 1-101-005-00 CERAMIC 22000PF 50V
C410 1-126-943-11 ELECT 2200uF 20% 25V
C415 1-126-935-11 ELECT 470uF 20% 16V
C416 1-126-960-11 ELECT 1uF 20% 50V
C417 1-126-942-61 ELECT 1000uF 20% 25V
C418 1-104-664-11 ELECT 47uF 20% 25V
C419 1-104-664-11 ELECT 47uF 20% 25V
0C421 1-113-889-11 CERAMIC 0.001uF 10% 250V
< CONNECTOR >
* CN402 1-573-457-11 PLUG, CONNECTOR 6P
< DIODE >
D401 8-719-077-63 DIODE 1N5402
D402 8-719-077-63 DIODE 1N5402
D403 8-719-077-63 DIODE 1N5402
D404 8-719-077-63 DIODE 1N5402
D405 8-719-200-02 DIODE 10E2
D406 8-719-200-02 DIODE 10E2
D407 8-719-200-02 DIODE 10E2
D408 8-719-200-02 DIODE 10E2
D409 8-719-991-33 DIODE 1SS133T-77
D411 8-719-200-02 DIODE 10E2
D412 8-719-200-02 DIODE 10E2
D413 8-719-200-02 DIODE 10E2
D414 8-719-200-02 DIODE 10E2
< FUSE >
0F401 1-533-470-11 FUSE, GLASS TUBE (DIA. 5) (T3.15AL/250V)
(AEP, UK, E, AUS)
0F401 1-533-690-11 FUSE, GLASS CYLINDRICAL (DIA. 5)
(3.15A/125V) (US, CND)
0F402 1-533-296-11 FUSE, GLASS CYLINDRICAL (DIA. 5)
(2A/125V) (US, CND)
0F402 1-533-468-11 FUSE, GLASS TUBE (DIA. 5) (T2AL/250V)
(AEP, UK, E, AUS)
< TRANSISTOR >
Q401 8-729-820-24 TRANSISTOR 2SC3330-T-TP
Q402 8-729-116-82 TRANSISTOR 2SD1616-L
Q403 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q404 8-729-116-82 TRANSISTOR 2SD1616-L
< RESISTOR >
R402 1-247-839-11 CARBON 2.2K 5% 1/4W
R403 1-249-441-11 CARBON 100K 5% 1/4W
R404 1-249-393-11 CARBON 10 5% 1/4W
R405 1-249-421-11 CARBON 2.2K 5% 1/4W
R410 1-249-410-11 CARBON 270 5% 1/4W
R411 1-249-393-11 CARBON 10 5% 1/4W
0R412 1-216-478-11 METAL OXIDE 390 5% 3W F
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
POWER
< RELAY >
0RL401 1-755-446-11 RELAY (AEP, UK, EA, SP, AR, AUS)
0RL401 1-755-448-11 RELAY (US, CND, MX, TW)
< TRANSFORMER >
0TR402 1-437-462-11 TRANSFORMER, POWER
(AEP, UK, EA, SP, AR, AUS)
0TR402 1-437-475-11 TRANSFORMER, POWER (US, CND, MX, TW)
< DIODE >
ZD401 8-719-109-97 DIODE RD6.8ES-B2
**************************************************************
MISCELLANEOUS
**************
06 1-555-750-00 CORD, POWER (EP30: AEP, UK, EA, SP/EP40)
06 1-696-966-31 CORD, POWER (EP30: AUS)
06 1-783-525-31 CORD, POWER (TRACKING) (EP30: TW, MX)
06 1-783-820-11 CORD, POWER (EP30: US, CND)
06 1-783-940-51 CORD, POWER (EP30: AR)
8 1-823-170-11 CORD (WITH CONNECTOR) (FM ANT)
64 1-796-190-11 DECK, MECH
157 1-471-144-11 MAGNET
166 1-796-189-11 MECH, CD
SW600 1-692-960-21 SWITCH, PUSH (1 KEY) (OPEN/CLOSE)
0TR401 1-437-463-11 TRANSFORMER, POWER
(EP30: AEP, UK, EA, SP, AR, AUS/EP40)
0TR401 1-437-476-11 TRANSFORMER, POWER
(EP30: US, CND, TW, MX)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-534-14 SCREW +BTP 2.6X8 TYPE2 N-S
#2 7-685-647-14 SCREW +BVTP 3X10 TYPE2 SLIT
#3 7-682-246-04 SCREW +K 3X5
#4 7-685-535-14 SCREW +BTP 2.6X10 TYPE2 N-S
#5 7-685-648-14 SCREW +BVTP 3X12 TYPE2 SLIT
#6 7-685-504-19 SCREW +BTP 2X6 TYPE2 N-S
#7 7-623-916-21 FIBER WASHER 3.3, SMALL
#8 7-685-233-19 SCREW +KTP 2.6X6 TYPE2NON-SLIT
#9 7-624-106-04 STOP RING 3.0, TYPE -E
#10 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#11 7-685-135-19 SCREW (+ PTPWH) (2.6X10)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
0 1-569-008-21 ADAPTOR, CONVERSION (EA, SP)
0 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
