HCD-EX6/EX6T/EX8/EX8T/EX9/EX9T
41
IC201 STK433-320-E (MAIN-AMP Board (2/2)) (HCD-EX9/EX9T only)
–PRE
1
–VCC
2
+VCC
3
SWIN–
12
SWIN+
11
LIN+
RIN+
RIN–
RO+
RO–
1514 16 17 18 19
ST-BY
13
LIN–
SWO+
4
SWO–
5
LO+
6
LO–
7
+PRE
8
SUB
9
GND
10
BIAS CIRCUIT
PRE DRIVER
CH1
PRE DRIVER
CH2
MONO IC
–
+
–
+
PRE DRIVER
CH3
–
+
–PRE
1
–VCC
2
+VCC
3
RIN–
12
RIN+
11
LIN+
15
ST-BY
13
LIN–
14
RO+
4
RO–
5
LO+
6
LO–
7
+PRE
8
SUB
9
GND
10
BIAS CIRCUIT
PRE DRIVER
CH1
PRE DRIVER
CH2
–++–
IC202 STK433-060 (MAIN-AMP Board (2/2)) (HCD-EX6/EX6T only)
