Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EX6/EX6T/EX8/EX8T/EX9/EX9T
5757
Q753 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (EX9/EX9T)
Q754 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF (EX9/EX9T)
Q755 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (EX9/EX9T)
Q756 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF (EX9/EX9T)
Q770 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q771 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q772 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R101 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
(EX8/EX8T)
R101 1-218-866-11 METAL CHIP 6.2K 0.5% 1/10W
(EX9/EX9T)
R102 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
(EX8/EX8T)
R102 1-218-866-11 METAL CHIP 6.2K 0.5% 1/10W
(EX9/EX9T)
R103 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R104 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R105 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R106 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R107 1-216-817-11 METAL CHIP 470 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R108 1-216-817-11 METAL CHIP 470 5% 1/10W
(EX8/EX8T/EX9/EX9T)
0 R109 1-215-890-11 METAL OXIDE 470 5% 2W F
0 R110 1-215-890-11 METAL OXIDE 470 5% 2W F
R111 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R112 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R113 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R114 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
0 R115 1-216-361-31 METAL OXIDE 0.22 5% 2W F
(EX8/EX8T/EX9/EX9T)
0 R116 1-216-361-31 METAL OXIDE 0.22 5% 2W F
(EX8/EX8T/EX9/EX9T)
R117 1-249-401-11 CARBON 47 5% 1/4W
R118 1-249-401-11 CARBON 47 5% 1/4W
R121 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
(EX8/EX8T)
R122 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
(EX8/EX8T)
R123 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EX8/EX8T)
R124 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EX8/EX8T)
R125 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EX8/EX8T)
R126 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EX8/EX8T)
R127 1-216-817-11 METAL CHIP 470 5% 1/10W
(EX8/EX8T)
R128 1-216-817-11 METAL CHIP 470 5% 1/10W
(EX8/EX8T)
R131 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EX8/EX8T)
R132 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EX8/EX8T)
R133 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(EX8/EX8T)
R134 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(EX8/EX8T)
0 R135 1-216-361-31 METAL OXIDE 0.22 5% 2W F
(EX8/EX8T)
0 R136 1-216-361-31 METAL OXIDE 0.22 5% 2W F
(EX8/EX8T)
R141 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R142 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R143 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R144 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R145 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R146 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R151 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
(EX8/EX8T)
R152 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
(EX8/EX8T)
R153 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EX8/EX8T)
R154 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EX8/EX8T)
R155 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EX8/EX8T)
R156 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EX8/EX8T)
R161 1-216-813-11 METAL CHIP 220 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R162 1-216-813-11 METAL CHIP 220 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R163 1-216-813-11 METAL CHIP 220 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R164 1-216-813-11 METAL CHIP 220 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R165 1-216-813-11 METAL CHIP 220 5% 1/10W
(EX8/EX8T)
R166 1-216-813-11 METAL CHIP 220 5% 1/10W
(EX8/EX8T)
R167 1-216-813-11 METAL CHIP 220 5% 1/10W
(EX8/EX8T)
R168 1-216-813-11 METAL CHIP 220 5% 1/10W
(EX8/EX8T)
R181 1-216-845-11 METAL CHIP 100K 5% 1/10W
R182 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R183 1-216-833-11 METAL CHIP 10K 5% 1/10W
R184 1-216-833-11 METAL CHIP 10K 5% 1/10W
R190 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R191 1-216-809-11 METAL CHIP 100 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R192 1-216-833-11 METAL CHIP 10K 5% 1/10W
R193 1-216-821-11 METAL CHIP 1K 5% 1/10W
R194 1-216-841-11 METAL CHIP 47K 5% 1/10W
R201 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
(EX6/EX6T)
R201 1-218-866-11 METAL CHIP 6.2K 0.5% 1/10W
(EX9/EX9T)
R202 1-218-866-11 METAL CHIP 6.2K 0.5% 1/10W
(EX9/EX9T)
MAIN-AMP
