Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EX6/EX6T/EX8/EX8T/EX9/EX9T
64
R014 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
(EX6/EX6T)
R014 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R015 1-216-839-11 METAL CHIP 33K 5% 1/10W
R016 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
(EX6/EX6T)
R016 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EX8/EX8T/EX9/EX9T)
R017 1-216-833-11 METAL CHIP 10K 5% 1/10W
R018 1-216-833-11 METAL CHIP 10K 5% 1/10W
R019 1-216-833-11 METAL CHIP 10K 5% 1/10W
R020 1-216-833-11 METAL CHIP 10K 5% 1/10W
R021 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R022 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R023 1-216-809-11 METAL CHIP 100 5% 1/10W
R024 1-216-809-11 METAL CHIP 100 5% 1/10W
R025 1-216-833-11 METAL CHIP 10K 5% 1/10W
R026 1-216-833-11 METAL CHIP 10K 5% 1/10W
R027 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R028 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R029 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R030 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R031 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R032 1-216-841-11 METAL CHIP 47K 5% 1/10W
R033 1-216-845-11 METAL CHIP 100K 5% 1/10W
R034 1-216-849-11 METAL CHIP 220K 5% 1/10W
R035 1-216-833-11 METAL CHIP 10K 5% 1/10W
R036 1-216-833-11 METAL CHIP 10K 5% 1/10W
R037 1-216-841-11 METAL CHIP 47K 5% 1/10W
R038 1-216-837-11 METAL CHIP 22K 5% 1/10W
R039 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R050 1-216-833-11 METAL CHIP 10K 5% 1/10W
R051 1-216-848-11 METAL CHIP 180K 5% 1/10W
R052 1-216-851-11 METAL CHIP 330K 5% 1/10W
R053 1-216-841-11 METAL CHIP 47K 5% 1/10W
R054 1-216-833-11 METAL CHIP 10K 5% 1/10W
R055 1-216-845-11 METAL CHIP 100K 5% 1/10W
R057 1-216-817-11 METAL CHIP 470 5% 1/10W
R058 1-216-817-11 METAL CHIP 470 5% 1/10W
R059 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R060 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R061 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R062 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R063 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R064 1-216-818-11 METAL CHIP 560 5% 1/10W
R066 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R067 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R068 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R069 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R070 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R071 1-216-845-11 METAL CHIP 100K 5% 1/10W
R072 1-216-833-11 METAL CHIP 10K 5% 1/10W
R073 1-216-833-11 METAL CHIP 10K 5% 1/10W
R074 1-216-843-11 METAL CHIP 68K 5% 1/10W
R075 1-216-821-11 METAL CHIP 1K 5% 1/10W
R076 1-216-817-11 METAL CHIP 470 5% 1/10W
R077 1-216-817-11 METAL CHIP 470 5% 1/10W
< RELAY >
0 RY001 1-755-334-11 RELAY, AC POWER (MX)
0 RY002 1-755-496-11 RELAY (EXCEPT MX)
< VOLTAGE SELECTOR >
0 S001 1-786-408-11 SELECTOR, VOLTAGE (SWS-2301)
(VOLTAGE SELECTOR) (E2,E4,E51)
*************************************************************
REG BOARD
**********
< CAPACITOR >
C697 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C698 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< IC >
IC690 6-713-032-01 IC KIA7809API-U/PF
*************************************************************
USB BOARD
**********
< CAPACITOR >
C900 1-117-681-11 ELECT CHIP 100uF 20% 16V
C901 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C902 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C903 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C904 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C905 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C906 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C907 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C908 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C909 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C915 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C916 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C917 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C918 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C919 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C920 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C921 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C950 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C951 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C952 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C953 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C954 1-126-601-11 ELECT CHIP 2.2uF 20% 50V
C955 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
< CONNECTOR >
CN901 1-784-382-51 CONNECTOR, FFC/FPC 25P
CN902 1-784-382-51 CONNECTOR, FFC/FPC 25P
CN903 1-764-250-11 PIN, CONNECTOR (PC BOARD) 4P
CN910 1-784-366-51 CONNECTOR, FFC/FPC 7P
< IC >
IC901 A-1768-193-A IC LC87F1JJ2AU-SQFP-H (for SERVICE)
< RESISTOR >
R900 1-216-864-11 SHORT CHIP 0
R901 1-216-809-11 METAL CHIP 100 5% 1/10W
R902 1-216-809-11 METAL CHIP 100 5% 1/10W
R903 1-216-857-11 METAL CHIP 1M 5% 1/10W
R904 1-216-864-11 SHORT CHIP 0
PT-POWER REG USB
