86
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN1000D
EFFECTOR
A-1193-302-A EFFECTOR BOARD, COMPLETE
************************
< CAPACITOR >
C1506 1-136-495-11 FILM 0.068uF 5% 50V
C1507 1-136-495-11 FILM 0.068uF 5% 50V
C1509 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C1512 1-126-964-11 ELECT 10uF 20% 50V
C1513 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1515 1-126-947-11 ELECT 47uF 20% 35V
C1516 1-136-495-11 FILM 0.068uF 5% 50V
C1517 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C1519 1-126-960-11 ELECT 1uF 20% 50V
C1520 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C1521 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C1522 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C1523 1-136-495-11 FILM 0.068uF 5% 50V
C1524 1-126-957-11 ELECT 0.22uF 20% 50V
C1525 1-126-957-11 ELECT 0.22uF 20% 50V
C1526 1-136-497-81 FILM 0.1uF 5% 50V
C1528 1-126-967-11 ELECT 47uF 20% 50V
C1529 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C1530 1-136-159-00 FILM 0.033uF 5% 50V
C1542 1-130-479-00 MYLAR 0.0047uF 5% 50V
C1544 1-130-479-00 MYLAR 0.0047uF 5% 50V
C1545 1-126-964-11 ELECT 10uF 20% 50V
C1546 1-126-964-11 ELECT 10uF 20% 50V
C1548 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1552 1-126-964-11 ELECT 10uF 20% 50V
C1554 1-126-964-11 ELECT 10uF 20% 50V
C1555 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1559 1-126-964-11 ELECT 10uF 20% 50V
C1560 1-126-964-11 ELECT 10uF 20% 50V
C1561 1-126-964-11 ELECT 10uF 20% 50V
C1562 1-126-964-11 ELECT 10uF 20% 50V
C1568 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1569 1-126-964-11 ELECT 10uF 20% 50V
C1570 1-126-964-11 ELECT 10uF 20% 50V
C1571 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1572 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1576 1-126-964-11 ELECT 10uF 20% 50V
C1578 1-126-964-11 ELECT 10uF 20% 50V
C1584 1-104-658-91 ELECT 100uF 20% 10V
< CONNECTOR >
CN1501 1-779-285-11 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
< DIODE >
D1502 8-719-069-56 DIODE UDZSTE-176.2B
< IC >
IC1500 8-759-710-97 IC NJM4565M-D
IC1501 8-759-496-41 IC M65850FP-E1
IC1503 6-709-217-01 IC TC74LVX4051FT
IC1505 8-759-710-97 IC NJM4565M-D
IC1506 6-709-218-01 IC TC74LVX4052FT
< COIL >
L1500 1-414-183-41 INDUCTOR 10uH
< TRANSISTOR >
Q1502 8-729-055-10 TRANSISTOR 2SK3378ENTL
Q1506 8-729-055-10 TRANSISTOR 2SK3378ENTL
Q1507 8-729-056-46 TRANSISTOR 2SC5053T100Q
Q1508 8-729-055-10 TRANSISTOR 2SK3378ENTL
Q1509 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1510 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1500 1-216-809-11 METAL CHIP 100 5% 1/10W
R1501 1-216-809-11 METAL CHIP 100 5% 1/10W
R1502 1-216-809-11 METAL CHIP 100 5% 1/10W
R1504 1-216-809-11 METAL CHIP 100 5% 1/10W
R1505 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1508 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1510 1-216-836-11 METAL CHIP 18K 5% 1/10W
R1511 1-216-836-11 METAL CHIP 18K 5% 1/10W
R1512 1-216-836-11 METAL CHIP 18K 5% 1/10W
R1514 1-216-836-11 METAL CHIP 18K 5% 1/10W
R1515 1-216-836-11 METAL CHIP 18K 5% 1/10W
R1516 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1517 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1519 1-216-864-11 SHORT CHIP 0
R1520 1-216-864-11 SHORT CHIP 0
R1522 1-216-864-11 SHORT CHIP 0
R1525 1-216-809-11 METAL CHIP 100 5% 1/10W
R1526 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1527 1-216-809-11 METAL CHIP 100 5% 1/10W
R1528 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1529 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1530 1-216-815-11 METAL CHIP 330 5% 1/10W
R1531 1-216-817-11 METAL CHIP 470 5% 1/10W
R1532 1-216-820-11 METAL CHIP 820 5% 1/10W
R1533 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R1534 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R1535 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R1536 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R1537 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1538 1-216-838-11 METAL CHIP 27K 5% 1/10W
R1546 1-216-836-11 METAL CHIP 18K 5% 1/10W
R1547 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1549 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1550 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1557 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1558 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1559 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1560 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1565 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1566 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1567 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1568 1-216-837-11 METAL CHIP 22K 5% 1/10W
