Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN1000D
R1569 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1570 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1571 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1572 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1573 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1574 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1575 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1576 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1579 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1580 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1581 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1582 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1584 1-216-864-11 SHORT CHIP 0
R1585 1-216-864-11 SHORT CHIP 0
R1586 1-216-864-11 SHORT CHIP 0
R1589 1-216-803-11 METAL CHIP 33 5% 1/10W
R1590 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1591 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1592 1-216-864-11 SHORT CHIP 0
R1594 1-216-836-11 METAL CHIP 18K 5% 1/10W
R1595 1-216-836-11 METAL CHIP 18K 5% 1/10W
R1600 1-216-838-11 METAL CHIP 27K 5% 1/10W
R1601 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1602 1-216-838-11 METAL CHIP 27K 5% 1/10W
R1603 1-216-845-11 METAL CHIP 100K 5% 1/10W
************************************************************
A-1156-227-A FUNCTION BOARD, COMPLETE
************************
< CAPACITOR >
C907 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C965 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C966 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C969 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C970 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C971 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C976 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C984 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
* CN901 1-569-934-11 SOCKET, CONNECTOR 17P
CNS902 1-820-050-11 BOARD TO BOARD HEADER (8P)
< DIODE >
D1017 6-500-725-01 DIODE SLR-343VCT32 (DELAY)
D1020 6-500-725-01 DIODE SLR-343VCT32 (FLANGER)
< JUMPER RESISTOR >
JR921 1-216-864-11 SHORT CHIP 0
JR923 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q921 8-729-027-50 TRANSISTOR DTC123JKA-T146
< RESISTOR >
R958 1-216-819-11 METAL CHIP 680 5% 1/10W
R959 1-216-821-11 METAL CHIP 1K 5% 1/10W
R960 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R961 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R962 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R963 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R972 1-216-821-11 METAL CHIP 1K 5% 1/10W
R973 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1001 1-216-817-11 METAL CHIP 470 5% 1/10W
R1002 1-216-819-11 METAL CHIP 680 5% 1/10W
R1003 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1004 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1005 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1006 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1014 1-216-817-11 METAL CHIP 470 5% 1/10W
R1018 1-216-819-11 METAL CHIP 680 5% 1/10W
R1186 1-216-814-11 METAL CHIP 270 5% 1/10W
< SWITCH >
S901 1-762-875-21 SWITCH, KEYBOARD (PROGRESSIVE)
S902 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S903 1-762-875-21 SWITCH, KEYBOARD (EQ BAND)
S904 1-762-875-21 SWITCH, KEYBOARD (DIRECTION)
S905 1-762-875-21 SWITCH, KEYBOARD (REC PAUSE/START)
S906 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
S914 1-762-875-21 SWITCH, KEYBOARD (ENTER)
S915 1-762-875-21 SWITCH, KEYBOARD (SOUND FLASH)
S916 1-762-875-21 SWITCH, KEYBOARD (DELAY)
S917 1-762-875-21 SWITCH, KEYBOARD (FLANGER)
S918 1-762-875-21 SWITCH, KEYBOARD (SOUND FIELD)
S919 1-762-875-21 SWITCH, KEYBOARD (ILLUMINATION)
S920 1-762-875-21 SWITCH, KEYBOARD (AMP MENU)
S928 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S970 1-418-725-61 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
************************************************************
A-1156-244-A JOG BOARD, COMPLETE
*******************
< CAPACITOR >
C1150 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CNS903 1-562-573-31 SOCKET, CONNECTOR 8P
< DIODE >
D919 6-500-809-01 DIODE SELU5223C-STP15 (VOL 1)
D920 6-500-809-01 DIODE SELU5223C-STP15 (VOL 2)
D921 6-500-809-01 DIODE SELU5223C-STP15 (VOL 3)
D922 6-500-809-01 DIODE SELU5223C-STP15 (VOL 4)
D923 6-500-809-01 DIODE SELU5223C-STP15 (VOL 5)
D924 6-500-809-01 DIODE SELU5223C-STP15 (VOL 6)
D925 6-500-809-01 DIODE SELU5223C-STP15 (VOL 7)
D926 6-500-809-01 DIODE SELU5223C-STP15 (VOL 8)
< JUMPER RESISTOR >
JR1 1-216-864-11 SHORT CHIP 0
JR2 1-216-864-11 SHORT CHIP 0
