Sony HCD-GR7 - Page 77

– 102 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
R124 1-249-429-11 CARBON 10K 5% 1/4W
R125 1-249-441-11 CARBON 100K 5% 1/4W
R126 1-249-417-11 CARBON 1K 5% 1/4W
R127 1-249-441-11 CARBON 100K 5% 1/4W
R131 1-260-076-11 CARBON 10 5% 1/2W
(RX70: AEP, AED, CIS, EE, G, UK)
R132 1-260-076-11 CARBON 10 5% 1/2W
(RX70: AEP, AED, CIS, EE, G, UK)
R133 1-260-091-11 CARBON 220 5% 1/2W
R134 1-260-091-11 CARBON 220 5% 1/2W
R140 1-249-429-11 CARBON 10K 5% 1/4W
R141 1-249-437-11 CARBON 47K 5% 1/4W
R142 1-249-429-11 CARBON 10K 5% 1/4W
! R147 1-215-891-11 METAL OXIDE 680 5% 2W F
(RX70: AEP, AED, CIS, EE, G, UK)
! R147 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
(D60/RX70: US, CND)
! R147 1-216-456-00 METAL OXIDE 820 5% 2W F
(GR7/GR7J)
R171 1-249-424-11 CARBON 3.9K 5% 1/4W
R172 1-247-887-00 CARBON 220K 5% 1/4W
R173 1-249-426-11 CARBON 5.6K 5% 1/4W
R174 1-249-429-11 CARBON 10K 5% 1/4W
R176 1-249-417-11 CARBON 1K 5% 1/4W
R177 1-249-441-11 CARBON 100K 5% 1/4W
R181 1-260-076-11 CARBON 10 5% 1/2W
(RX70: AEP, AED, CIS, EE, G, UK)
R182 1-260-076-11 CARBON 10 5% 1/2W
(RX70: AEP, AED, CIS, EE, G, UK)
R183 1-260-091-11 CARBON 220 5% 1/2W
R184 1-260-091-11 CARBON 220 5% 1/2W
R191 1-249-425-11 CARBON 4.7K 5% 1/4W
(D60/GR7/GR7J/RX70: US, CND)
R192 1-249-441-11 CARBON 100K 5% 1/4W
(D60/GR7/GR7J/RX70: US, CND)
R193 1-249-421-11 CARBON 2.2K 5% 1/4W
(D60/GR7/GR7J/RX70: US, CND)
R194 1-249-437-11 CARBON 47K 5% 1/4W
(D60/GR7/GR7J/RX70: US, CND)
R195 1-249-437-11 CARBON 47K 5% 1/4W
(D60/GR7/GR7J/RX70: US, CND)
R201 1-249-429-11 CARBON 10K 5% 1/4W
R202 1-247-863-91 CARBON 22K 5% 1/4W
(GR7: EA4, SAF, TH)
R202 1-249-433-11 CARBON 22K 5% 1/4W
(EXCEPT GR7: EA4, SAF, TH)
R203 1-249-441-11 CARBON 100K 5% 1/4W
R205 1-247-863-91 CARBON 22K 5% 1/4W
(GR7: EA4, SAF, TH)
R205 1-249-433-11 CARBON 22K 5% 1/4W
(EXCEPT GR7: EA4, SAF, TH)
L393 1-410-515-11 INDUCTOR 33uH
< TRANSISTOR >
Q101 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q102 8-729-900-63 TRANSISTOR DTA124ES
Q103 8-729-900-36 TRANSISTOR DTC124ES
Q141 8-729-119-76 TRANSISTOR 2SA1175-HFE
(EXCEPT D60/RX70: US, CND)
Q141 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
(D60/RX70:US, CND)
Q142 8-729-119-78 TRANSISTOR 2SC403SP-51
(EXCEPT D60/RX70: US, CND)
Q142 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
(D60/RX70:US, CND)
Q151 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q191 8-729-119-76 TRANSISTOR 2SA1175-HFE
(D60/GR7/GR7J/RX70: US, CND)
Q192 8-729-111-29 TRANSISTOR 2SD1616A-K
(D60/GR7/GR7J/RX70: US, CND)
Q202 8-729-119-78 TRANSISTOR 2SC403SP-51
Q203 8-729-119-78 TRANSISTOR 2SC403SP-51
Q204 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q231 8-729-900-63 TRANSISTOR DTA124ES
Q232 8-729-900-63 TRANSISTOR DTA124ES
Q241 8-729-141-30 TRANSISTOR 2SC3623A-LK
(GR7/GR7J/RX70: US, CND)
Q252 8-729-119-78 TRANSISTOR 2SC403SP-51
Q253 8-729-119-78 TRANSISTOR 2SC403SP-51
Q254 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q281 8-729-900-36 TRANSISTOR DTC124ES
Q282 8-729-900-63 TRANSISTOR DTA124ES
Q283 8-729-900-36 TRANSISTOR DTC124ES
Q301 8-729-119-78 TRANSISTOR 2SC403SP-51
Q901 8-729-040-20 TRANSISTOR RT1P137L-TP
Q902 8-729-900-36 TRANSISTOR DTC124ES
Q903 8-729-030-18 TRANSISTOR 2SD2525
Q904 8-729-030-19 TRANSISTOR 2SB1640
Q905 8-729-040-20 TRANSISTOR RT1P137L-TP
Q906 8-729-900-63 TRANSISTOR DTA124ES
Q907 8-729-119-78 TRANSISTOR 2SC403SP-51
Q1531 8-729-801-93 TRANSISTOR 2SD1387
Q1532 8-729-900-80 TRANSISTOR DTC114ES
Q1533 8-729-900-80 TRANSISTOR DTC114ES
Q1534 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q1535 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R121 1-249-424-11 CARBON 3.9K 5% 1/4W
R122 1-247-887-00 CARBON 220K 5% 1/4W
R123 1-249-426-11 CARBON 5.6K 5% 1/4W
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
